Hanyoung RT9 Quick Start Guide

Signal Name Description Condition Initial value
Communication group
RS4 85/RS422
P r o t o c o l
Communication rate
( B . P . S )
Parity check
Stop bit
Data length
A d d r e s s
Response time
Set communication mode
PC.LINK(Set value:0) / PC.LINK SUM (Set value:1)
6 00( S V:0) / 1200( S V:1) / 2400( S V:2)
4 8 00( S V:3) / 9600( S V:4)
N O N E ( S V : 0)/ E V E N ( S V : 1)/ O D D ( S V : 2 )
1bit (SV:1) / 2bit (SV:2 )
7bit (SV:7) / 8bit (SV:8)
(Except PC LINK :8 )
1~99 , maximum 31 devices
0~10. response time = (handling time + response
time) X 10ms
Optional
0
4
1
1
8
1
0
2019
5) Communication group setting( O p t i o n a l )
6) Output group setting ( M o d e l : RT9-1)
(△ : Set point , : Minus Alarm set point , ▲ : Alarm set point )
Code
NO.
1
2
3
4
5
6
7
8
9
1 0
1 1
1 2
1 3
1 4
1 5
1 6
1 7
1 8
1 9
2 0
High absolute value
Low absolute value
High deviation value
Low deviation value
High deviation value (inverted)
Low deviation value (inverted)
High·Low deviation value
High·Low band
High absolute (inverted)
Low absolute (inverted)
High absolute with hold function
Low absolute with hold function
High deviation with hold function
Low deviation with hold function
High deviation with hold function
(inverted)
Low deviation with hold function
(inverted)
High·Low deviation with hold
function
High·Low band with hold
function
High absolute value with hold
function (inverted)
Low absolute value with hold
function (inverted)
Function
ALARM TYPE AND CODE
Alarm type
※
H y s t e r e s i s
(Notice) : Display lamp will be ON when output OFF in inverted type.
*
*
*
*
*
*
*
*
*
*
*
*
*
Marked alarms are not available in RT9-0
NX series are equipped with 4 wire /2 wire half-duplex the RS485 / RS422 communication
interfaces.Using the interfaces, communications are available with maximum 31 devices.
Output group
Output signal
Output operation
Cycle time
Hysteresis of universal type
Hysterecis of Heating/Cooling type
Output volume when input
disconnection Output (Out)
Maximum value of output
Minimum value of output
Always
Output code
1 ~ 3
Relay / SSR
ON/OFF Control
H e a t i n g / C o o l i n g
Always
Except ON/OFF
Except ON/OFF
3
R E V
30 sec
0
0 . 5 %
0 . 0 %
1 0 0 . 0 %
0.0 %
Signal Name Description Conditi Initial value
Output type and mode selection
Refor to type of control output
REV: Reverse DIR: Direct action
1~1000 sec
EUS(0.0~100.0%)
0.0~10.0%
-5.0~105.0%
OL-L + 1Digit~ 105.0%
-0.5%~ OL-H-1Digit
M o d e l : R T 9 - 1
When setting, “Input type selection number” must be selected in the input type selection
mode and also “Output type selection number”must be selected in the output type selection
mode before moving to other mode.
If not, data of other group will be changed to prior value.
CAUTION
Output is selectable from Relay, SSR and Current(4~20mA DC)
For Recorder & Controller, output code 0~3 are available for your use.
