6 7
INITIAL INSTRUCTIONS INITIAL INSTRUCTIONS
1. Determine mounting method to use.
A - Downrod Mount (normal or angled ceiling)
B - Closemount (normal ceiling only)
Important: lf using the angle mount, check to
make sure the ceiling angle is not steeper than 20°.
4. Install the mounting bracket (A) to the outlet box
(not included) using the two screws provided
with the outlet box. Securely tighten the two
screws.
2. Removeanddiscardtheverubberinsertsand
thevemountingscrewsfromtheundersideofthe
motor assembly (E).
2a.
Outlet box
A
4
3. Remove the mounting bracket (A) from the canopy
(B) by loosening the four screws on the top of the
canopy (B). Remove the two non-slotted screws and
save.
1
A
B
Loosen but
do not remove
A
Remove
and save
A
B
3
If using the angle mount, make sure open end of
mounting bracket (A) is installed facing the highest
point of the ceiling.
Follow mounting instructions for Downrod Style
Fan Mounting on page 7 or Closemount Style
Fan Mounting on page 9, depending on mounting
method (A or B) chosen in step 1 on page 6.
DOWNROD STYLE FAN MOUNTING
1. Remove pin and clip from downrod (D) and save.
E
2
C
B
D
E
D
Clip
Pin
1
2a
STANDARD DOWNROD INSTALLATION: Insert
downrod (D) through canopy (B) and canopy cover
(C). Thread wires from the motor assembly (E)
through downrod (D).
Lowes.com/harborbreeze Lowes.com/harborbreeze
Page 6 Page 7
