HARDWARE CONTENTS (shown actual size)
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 45 minutes
Tools Required for Assembly (not included): Phillips screwdriver, step ladder, electrical tape, pliers,
wire cutters, wire strippers.
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Mounting Plate 1
B Motor 1
C Switch Housing Plate (preassembled to motor (B)) 1
D Motor Housing 1
E Blade Bracket 5
F Blade 5
G Switch Housing 1
H Light Kit 1
I Glass Bowl 1
J Bowl Cap (preassembled to light kit (H)) 1
K Finial (preassembled to light kit (H)) 1
L Bulb 2
B
A
C
F
G
H
D
I
J
K
L
E
CC
DD
BB
EE
FF
AA
Wire Connector
Qty. 3 + 1 extra
Lock Nut
Qty. 3
Blade Screw
Qty. 15 + 1 extra
Blade Bracket Screw
with Washer
Qty. 10 + 1 extra
Fan Pull Chain
Extension
Qty. 1
Light Pull Chain
Extension
Qty. 1
