Harbor Breeze 0807431 - Mounting Installation; Upper Mounting Bracket

8
INITIAL INSTALLATION
4. Secure the upper mounting bracket (A) to the
outlet box (not included) using screws and washers
provided with the outlet box.
CAUTION: It is very important you use the proper
hardware when installing the upper mounting bracket
(A) as it will support the fan.
4
5. Remove the preassembled lower bracket screw (K)
from the lower mounting bracket (B) and the upper
bracket screws (P) from the upper mounting bracket
(A). Insert the tab of the lower mounting bracket (B)
into the slot in the upper mounting bracket (A).
A
P
K
B
6. Re-install the previously removed lower bracket screw
(K) and upper bracket screws (P) to secure the lower
mounting bracket (B) to the upper mounting bracket (A).
A
5
6
A
P
K
B
B
A
P
K
