STANDARD OR ANGLE MOUNTING INSTRUCTIONS
4. Install the ball end of the downrod (A) into the opening of
the mounting bracket (E). Rotate the fan in the mounting
bracket (E) until a slot in the ball end of the downrod (A)
engages the tab in the mounting bracket (E).
DANGER: The fan and/or downrod should not
rotate in the mounting bracket (E) if installed correctly.
Failure to align the slot with the tab may result in fan
falling causing serious injury or death.
5. Insert the receiver from remote pack (P) into the
mountingbracket(E)withtheatsideofthereceiver
facing the ceiling.
WARNING: Using a full-range dimmer switch to
control fan will cause a loud humming noise from the
fananddamagetheremote.Toreducetheriskofre
or electric shock, do NOT use a full-range dimmer
switch to control the fan speed.
Proceed to WIRING on page 12.
4
A
A
E
E
Tab
Slot
E
5
Receiver
