PACKAGE CONTENTS
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
5
A
C
I
L
H
F
G
E
J
PART DESCRIPTION QUANTITY
A Motor Housing 1
B Mounting Bracket 1
C Extra Switch Housing 1
D Motor Assembly 1
E Light Kit Fitter 1
F Glass Shade 4
G Blade Arm 5
H Blade 5
I Candelabra Base Bulb 4
J Pull Chain Extension 2
K Mounting Bracket Nut 4
(preassembled)
PART DESCRIPTION QUANTITY
L Socket Ring 4
(preassembled)
M Motor Screw 10
(preassembled)
N Lock Washer 10
(preassembled)
O Motor Housing Mounting 4
Screw (preassembled)
P Mounting Bracket Flat 4
Washer (preassembled)
Q Motor Housing Lock 4
Washer (preassembled)
R Switch Housing Plate 3
Screw (preassembled)
N
M
D
B
P
K
O
Q
R
To Next Page
