Harbor Breeze CHESHIRE II CSD52BB5C4 User Manual

INITIAL INSTALLATION
H
Turn off circuit breakers and wall switch to the fan
supply line leads. (Fig. 1)
DANGER: Failure to disconnect power supply
prior to installation may result in serious injury or
death.
1.
2.
ON
OFF
ON
OFF
1
7 ft.
min.
30 in.
min.
2
3.
7
Remove all mounting bracket nuts (K) and
mounting bracket flat washers (P) from mounting
bracket (B). (Fig. 3)
B
K
P
3
Check to make sure blades (H) will be at least
30 in. from any obstruction and at least 7 ft.
above the floor. (Fig. 2)

Harbor Breeze CHESHIRE II CSD52BB5C4 Specifications

General

Brand	Harbor Breeze
Model	CHESHIRE II CSD52BB5C4
Category	Fan
Language	English
