Harbor Breeze WAVEPORT Series User Manual

6
Check to make sure blades (G) will be at least 30
inches from any obstruction and at least 7 ft. above
the floor.
3.
INITIAL INSTALLATION
7 ft.
min.
30 in.
min.
3
G
2.
Determine mounting method to use.
A. Downrod mount (standard or angled ceiling)
B. Closemount (standard ceiling only)
IMPORTANT: If using the angle mount, check to
make sure the ceiling angle is not steeper than 19°.
*Helpful Hint: Downrod-style mounting is best
suited for ceilings 8 ft. or higher. For taller ceilings
you may want to use a longer downrod (not
included). Angle-style mounting is best suited for
angled or vaulted ceilings. A longer downrod is
sometimes necessary to ensure proper blade
clearance.
B
A
2
4a.
Loosen canopy mounting screws (K) in slotted
holes in canopy (B) and remove the other two
canopy mounting screws (K) -- save canopy
mounting screws (K) for later use. Remove
mounting bracket (C) from canopy (B).
C
K
B
4a
K

Harbor Breeze WAVEPORT Series Specifications

General

Blade Material	ABS
Number of Blades	3
Motor Type	AC
Control Type	Remote Control
Damp/Wet Rating	Damp
Blade Span	52 inches
Number of Speeds	3
Mounting Options	Flush Mount
Reversible Motor	Yes
Warranty	Limited Lifetime
