8 - Technical specifications
105
Brakes
Max. wear rates on brake components:
Hydraulic brakes
Max. hydraulic pressure: 150 bar.
Airborne Noise Emission
Airborne noise emission from operating the sprayer relates to the two defined operator positions (in the tractor cab or
operating the chemical incorporator/filling device). Reference measurements indicate only in the latter case (operating the
chemical incorporator/filling device) a contribution from the sprayer of additionally 4 dB(A).
Sprayer volume Drum dimensions Max. drum diameter Min. lining thickness
5000 / 6000 litres 412 x 160 mm 414 mm 5.5 mm
