8 - Technical specifications
106
Tyre Pressure
Tyre pressure depends on:
• Actual axle load.
• Tyre size.
• Actual speed of the sprayer.
This means that it is often not possible to drive a fully loaded sprayer at maximum speed, when having narrow wheels
mounted.
÷
NOTE! Be aware of specific data for your sprayer.
±
WARNING! If changing tyres, always use tyres with minimum load index as specified.
€
DANGER! Never inflate tyres to more than the pressure specified in the table. Over-inflated tyres can explode causing
severe personal injuries!
10 km/h 20 km/h 30 km/h 40 km/h
Tyre size (“) Load index Max axle
load (kg)
Tyre pressure
(bar)
Max axle
load (kg)
Tyre pressure
(bar)
Max axle
load (kg)
Tyre pressure
(bar)
Max axle
load (kg)
Tyre pressure
(bar)
18.4x38 157 A8 11810 2.5 9030 2.5 8750 2.5 8250 2.5
520/85x42 167 A8 14720 2.5 11740 2.5 11420 2.5 10900 2.5
12.4x46 146 A8 7080 2.5 6720 2.5 6360 2.5 6000 2.5
14.9x46 159B A8 11920 2.5 11140 2.5 10360 2.5 9580 2.5
