Technical Specifications for AVR Surround Receiver
TECHNICAL SPECIFICATIONS FOR AVR
Audio Section
Stereo Mode
Continuous Average Power (FTC)
40 Watts per channel, 20Hz–20kHz,
@ < 0.07% THD, both channels driven into 8 ohms
Five-Channel Surround Modes
Power Per Individual Channel, all channels driven simultaneously
Front L&R channels:
35 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
35 Watts,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Surround channels:
35 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Five-Channel Surround Modes
(One channel driven into 6 ohms, 1kHz, @ <0.07% THD)
Front L&R channels:
70 Watts per channel
Center channel:
70 Watts
Surround (L & R) channels:
70 Watts per channel
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz–100kHz
High Instantaneous
Current Capability (HCC) ±25 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Rise Time 16µsec
Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/65dB (DIN)
Distortion Mono/Stereo: 0.15/0.3%
Stereo Separation 35dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 522–1620kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency
Response 10Hz–8MHz (–3dB)
General
Power Requirement AC 230V/50Hz
Power Consumption 72W idle, 580W maximum
(2 channels driven)
Dimensions (Max)
Width 440mm
Height 165mm
Depth 382mm
Weight 9.6 kg
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon and Logic 7 are trademarks of Harman International Industries, Incorporated,
registered in the United States and/or other countries.
Designed to Entertain is a trademark of Harman International Industries, Incorporated.
*Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, AC-3 and the
Double-D symbol are trademarks of Dolby Laboratories, Inc.
Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535; 7,003,467 & other U.S. and worldwide patents issued & pending. DTS, DTS Digital
Surround, ES, and Neo:6 are registered trademarks and the DTS logos Symbol are trademarks of
DTS, Inc. © 1996-2007 DTS, Inc. All Rights Reserved.
Logic 7 is a registered trademark of Lexicon, Inc.
HDMI is a trademark or registered trademark of HDMI Licensing LLC.
SACD is a trademark of Sony Corporation.
