No. PCB Name Ref. # Part No.(Makers) Part No.(ANAM) Description Makers
1 COP12185B (Front PCB Ass'y ) IC73 NJL34H380A HRVNJL34H380A INFRARED REMOTE CONTROL RECEIVER JRC
2 " IC75 74ACT04MTR HVI74ACT04MTR HEX INVERTER ST
3 " IC76 74HCU04AFNG HVI74HCU04AFNG HEX INVERTER TOSHIBA
4 " IC86 NJM4556AL HVINJM4556AL DUAL HIGH CURRENT OPERATIONAL AMPLIFIER JRC
5 " FIP1 162-BD-01GINK CFL162BD01GINK VACUUM FLUORESCENT DISPLAY TUBE FUTABA
No. PCB Name Ref. # Part No.(Makers) Part No.(ANAM) Description Makers
1 COP12186B (Main PCB Ass'y )
IC89
KIA278R05PI
HVIKIA278R05PI
4 TERMINAL 2A OUTPUT LOW DROP VOLTAGE REGULATOR KEC
2"
IC90
KIA278R15PI
CVIKIA278R15PI
4 TERMINAL 2A OUTPUT LOW DROP VOLTAGE REGULATOR KEC
3"
IC91
KIA7915PI
CVIKIA7915PI
1A THREE TERMINAL NEGATIVE VOLTAGE REGULATOR KEC
4"
IC94
KIA1117PI50
CVIKIA1117PI50
LOW DROP FIXED AND ADJUSTABLEPOSITIVE VOLTAGE REGULATOR KEC
5"
IC97
RE5VT28CATZ
HVIRE5VT28CATZ
LOW VOLTAGE DETECTOR RICOH
6"
Q653
2SB1559
CVT2SB1559P47M
Silicon PNP Epitaxial Planar Transistor SANKEN
7"
Q659
2SD2389
CVT2SD2389P47M
Silicon NPN Triple Diffused Planar Transistor SANKEN
8"
Q852
KD600K
HVTKD600KGR
EPITAXIAL PLANAR NPN TRANSISTOR KEC
No. PCB Name Ref. # Part No.(Makers) Part No.(ANAM) Description Makers
1 COP12187B (Input PCB Ass'y )
IC20
NJW1197C
CVINJW1197CFC2
8-CHANNEL ELECTRONIC VOLUME WITH INPUT SELECTOR JRC
2"
IC21~IC33
NJM2068M
HVINJM2068MDTE1
LOW NOISE DUAL OPERATIONAL AMPLIFIER JRC
3"
IC36
KA78L08AZ
HVIKA78L08AZT
3-Terminal 0.1A Positive Voltage Regulator FAIRCHILD
4"
IC37
KA79L08AZ
HVIKA79L08AZT
3-Terminal 0.1A Negative Voltage Regulator FAIRCHILD
5"
IC71
TC74HCU04AFNG HVI74HCU04AFNG HEX INVERTER TOSHIBA
6"
IC72
TC74HCU04AFNG
HVITC74HCU04AFN
HEX INVERTER TOSHIBA
7"
IC73
AK4589VQ
HVIAK4589VQ-T
2/8-Channel Audio CODEC with DIR AKM
8"
IC74
LC72723M
HVILC72723M
RDS Demodulation IC SANYO
9"
IC75
CS49510-CQ
CVICS49510-CQ
Multi-channel Audio DSP CIRRUS LOGIC
10 "
IC76 ES29LV800ET70TG CVIANAM1487AT
8MbitCMOS 3.0 Volt-only, Boot Sector Flash Memory ESI
11 "
IC77
57V161610ET7
HVI57V161610ET7
2 Banks x 512K x 16 Bit Synchronous DRAM HYNIX
12 "
IC78
NJM2391DL1-33
HVINJM2391DL133
LOW DROPOUT VOLTAGE REGULATOR JRC
13 "
IC79
KIA1117S18
CVIKIA1117S18
LOW DROP FIXED POSITIVE VOLTAGE REGULATOR KEC
14 "
IC87
RH5VT28C
HVIRH5VT28C
LOW VOLTAGE DETECTOR RICOH
15 "
IC88
KIA1117S33
CVIKIA1117S33
LOW DROP FIXED POSITIVE VOLTAGE REGULATOR KEC
16 "
IC89
M24C32WMN6TP
CVIM24C32WMN6TP
64Kbit and 32Kbit Serial I²C Bus EEPROM ST
17 "
IC90 T5CC1 CVIANAM1486AT
CMOS 16-Bit Microcontrollers TOSHIBA
18 "
IC91
74ACT04MTR HVI74ACT04MTR HEX INVERTER ST
No. PCB Name Ref. # Part No.(Makers) Part No.(ANAM) Description Makers
1 COP12188B (Video PCB Ass'y )
IC41
NJM2595M
CVINJM2595MTE1
5-INPUT 3-OUTPUT VIDEO SWITCH JRC
2"
IC61
NJW1321FP1
CVINJW1321FP1
WIDE BAND VIDEO SWITCH WITH I2C BUS JRC
3"
IC62
KIA7809API
HVIKIA7809API
THREE TERMINAL POSITIVE VOLTAGE REGULATORS KEC
No. PCB Name Ref. # Part No.(Makers) Part No.(ANAM) Description Makers
1 COP12109B (HDMI PCB Ass'y )
IC91
SII9185ACTU
CVISII9185ACTU
3:1 HDMI 1.3 Switch Silicon Image
2"
IC92
KIA1117S50
CVIKIA1117S50
LOW DROP FIXED POSITIVE VOLTAGE REGULATOR KEC
3"
IC93
KIA1117S33
CVIKIA1117S33
LOW DROP FIXED POSITIVE VOLTAGE REGULATOR KEC
4"
IC94
KIA1117S1
8
CVIKIA1117S18
LOW DROP FIXED POSITIVE VOLTAGE REGULATO
R
KEC
AVR139/230, AVR141/230, AVR142/230 IC List
harman/kardon
AVR 139-141-142/230 Service Manual
Page 30 of 83
