Harman Kardon AVR 140 Brochure & Specs

Model AVR 740 AVR 340 AVR 240 AVR 140 AVR 635 AVR 435 DPR 2005
Description 7.2-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 6.1-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 7.1-Channel DPR
Stereo Power (FTC) 100 x 2 70 x 2 65 x 2 50 x 2 90 x 2 80 x 2 120 x 2
Multichannel Power (FTC) 85 x 7 55 x 7 50 x 7 40 x 6 75 x 7 65 x 7 120 x 7
A
mplifier Type High current High current High current High current High current High current Advanced PWM
±60 amps ±35 amps ±35 amps ±25 amps ±50 amps ±40 amps
THD @ Impedance 0.07% @ 8Ω 0.07% @ 8Ω 0.07% @ 8Ω 0.07% @ 8Ω 0.07% @ 8Ω 0.07% @ 8Ω 0.15% @ 8Ω
Bandwidth 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz
B
andwidth @ 1W 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 20Hz – 20kHz
(+0dB/–3dB)
Signal-to-Noise Ratio 100dB 100dB 100dB 100dB 100dB 100dB 97dB
(IHF-A)
Power Supply Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear Switch mode
Dolby
®
Digital Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX Dolby
®
Digital EX
Dolby
®
Pro Logic
®
II Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx Pro Logic
®
IIx
Dolby
®
Virtual Speaker Yes Yes Yes No Yes Yes Yes
DTS
®
5.1 Yes Yes Yes Yes Yes Yes Yes
DTS-ES
®
6.1 Yes Yes Yes Yes Yes Yes Yes
Discrete & Matrix
DTS 96/24
®
Yes Yes Yes Yes Yes Yes Yes
DTS Neo:6
®
Yes Yes Yes Yes Yes Yes Yes
Logic 7 Yes Yes Yes Yes Yes Yes Yes
VMAx No Yes Yes Yes No No Yes
Headphone Modes 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP 2-Channel, Dolby
®
HP
XM-Ready Yes No No No No No No
Multizone Capability Audio/video with remote Audio, with remote No No Audio, with remote Audio, with remote Audio, with remote
Assignable Rear-Channel Yes Yes No No Yes Yes Yes
Amplifiers
A-BUS/READY
®
Yes Yes No No Yes Yes Yes
EzSet Capability EzSet/EQ II EzSet/EQ EzSet+ No EzSet/EQ EzSet/EQ EzSet
Model (continued) AVR 740 AVR 340 AVR 240 AVR 140 AVR 635 AVR 435 DPR 2005
A/V Inputs 5 5 5 4 5 5 5
S-Video Inputs 5 5 5 4 5 5 5
Analog Audio Inputs 3 3 3 3 4 4 4
D
igital Audio Inputs Rear panel 3/3 Rear panel 3/3 Rear panel 2/2 Rear panel 2/2 Rear panel 3/3 Rear panel 3/3 Rear panel 2/2
(Coax/Optical) Front panel 1/1 Front panel 1/1 Front panel 1/1 Front panel 1/1 Front panel 1/1 Front panel 1/1 Front panel 1/1
Digital Audio Outputs Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1
(Coax/Optical) Front panel 1/0 Front panel 1/0 Front panel 1/0
Digital Input Polling All video inputs All video inputs All video inputs All video inputs All video inputs All video inputs All video inputs
Direct Audio Inputs 7.1 With bass management 7.1 7.1 7.1 7.1 7.1 7.1 With bass management
HDMI
™
Inputs 2 0 0 0 0 0 0
HDMI
™
Output 1 With processing 0 0 0 0 0 0
Preamp Outputs 7.2 Channels 7.1 Channels 7.1 Channels Subwoofer 7.1 Channels 7.1 Channels 7.1 Channels
Component Video 3 @ 100MHz 2 @ 50MHz 2 @ 50MHz 2 @ 50MHz 2 @ 50MHz 2 @ 50MHz 2 @ 50MHz
Inputs (Assignable)
Bass Management Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover
On-Screen Display Yes, including component Yes Yes Yes Yes, including component Yes Yes
Input Titling All inputs All inputs All inputs All inputs A/V inputs A/V inputs A/V inputs
DSP Processor TI DA 610 Cirrus
®
CS 49400 Cirrus
®
CS 49400 Cirrus
®
CS 49400 TI DA 610 TI DA 610 Cirrus
®
CS 49400
Output DACs 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit
Video Processing/ DCDi
®
by Faroudja Composite/S to component No No Composite/S to component No No
Conversion scaling and processing cross conversion cross conversion
A/V Sync Delay 200 mS 80 mS 80 mS No 80 mS 80 mS 80 mS
IEC Detachable Power Cord Yes No No No Yes Yes Yes
System Remote TC 30 activity-based, 9-Device programmable 9-Device programmable 7-Device programmable 8-Device learning & 8-Device learning & 8-Device learning &
color LCD, Internet programmability programmable with backlit, programmable with backlit, programmable with backlit,
two-line LCD two-line LCD two-line LCD
IR In/Out Jacks Yes Yes Yes No Yes Yes Yes
IR Carrier Output Yes Yes No No Yes Yes No
Discrete Remote On/Off Codes Yes Yes Yes Yes Yes Yes Yes
Low-Voltage Trigger Jacks 2 No No No No No No
External Data Port USB and RS-232 No No No Bi-directional RS-232 Bi-directional RS-232 Bi-directional RS-232
Speaker Terminals Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts
Dimensions 6-1/2" x 17-5/16" x 17-1/8" 6-13/16" x 17-5/16" x 15" 6-13/16" x 17-5/16" x 15" 6-13/16" x 17-5/16" x 15"
6-1/2" x 17-5/16" x 17-1/8" 6-1/2" x 17-5/16" x 17-1/8" 4-1/2" x 17-5/16" x 18-3/4"
(H x W x D)
Weight 48 lb 31.7 lb 30.7 lb 24.5 lb 41 lb 39 lb 23 lb
Model The Bridge
Description iPod
®1
Docking Station
iPod
®
Requirements Third-generation and above iPod
®
with docking connector
(not compatible with iPod shuffle
™
)
Receiver Requirements Harman Kardon AVR with DMP/The Bridge docking connector
Dimensions (H x W x D) 1-3/16" x 4-1/2" x 4-1/2"
Weight 5.9 Ounces
Model TC 30
Description Activity-Based Remote
LCD Screen 64K color LCD
Maximum Devices 15
Maximum Activities 255
Memory 2MB
Computer Requirements PC with Microsoft
®
Windows
®
98SE/ME/2000/XP or Mac OS
®
X,
CD-ROM drive, USB port (dial-up or broadband Internet access required for programming)
Includes
TC 30,
installation disc
, USB cable, lithium-ion rechargeable battery,
charging cradle, AC adaptor, power supply
Remote Dimensions (H x
W x D)
8-7/8" x 2-1/8" x 1"
Charging Cradle Dimensions (H x W x D) 8-13/16" x 2-3/8" x 11/16"
Remote
W
eight 6 Ounces
Charging Cradle
W
eight
5 Ounces
Model AB 1
Description A-BUS/READ
Y
®
In-Wall Module With Built-In Amplifier
System Requirements Any Harman Kardon A-BUS/
READY
®
receiver,
or any receiver or source product connected to
an ABH 4. Connections via Cat. 5/5e cable.
Use with 6-ohm or 8-ohm speakers with
sensitivity >88dB. Includes IR sensor for
pass-through of remote commands.
Dimensions (H x W x D) 4-1/4" x 1-3/4" x 2-1/4"
Weight 0.25 lb
Model HE 1000
Description External Infrared Remote Sensor
System Requirements Harman Kardon or compatible products
with “IR Remote In” jack
Includes
P
ower supply
,
connecting block,
connecting cable
Unit Dimensions (H x W x D) 1" x 3-5/16" x 2-5/16"
Unit
W
eight 5.7 Ounces
Model ABH 4
Description 4-Room A-BUS
®
Expansion Hub
System Requirements AB 1 or other compatible A-BUS
®
modules.
Harman Kardon A-BUS/
READY
®
receiver
or any source device with standard analog
L/R outputs.
Dimensions (H x W x D) ABH 4: 3-5/16" x 7-3/16" x 1-3/16"
P
ower Supply:
1-7/16" x 5-15/16" x 2-13/16"
W
eight
ABH 4:
0.9 lb
Power Supply: 1 lb
SPECIFICATIONS
38 39

Harman Kardon AVR 140 Specifications

General

Brand	Harman Kardon
Model	AVR 140
Category	Receiver
Language	English
