Harman Kardon AVR 141/230

FRONT PCB ASSY
Ref. # Part Number
Description
V
alue
R904 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R905 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R906 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R907 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R908 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R909 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R910 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R911 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R912 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R913 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R915 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R918 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R919 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
S701 CST1A024ZT SW , TACT
S702 CST1A024ZT SW , TACT
S703 CST1A024ZT SW , TACT
S704 CST1A024ZT SW , TACT
S705 CST1A024ZT SW , TACT
S706 CST1A024ZT SW , TACT
S707 CST1A024ZT SW , TACT
S711 CST1A024ZT SW , TACT
S712 CST1A024ZT SW , TACT
S713 CST1A024ZT SW , TACT
S714 CST1A024ZT SW , TACT
S715 CST1A024ZT SW , TACT
BK71 CMD1A468 BRACKET , FLT
BK72 CMD1A468 BRACKET , FLT
BN10 CWB1B009450BM001 WIRE ASS'Y (9P,2.5MM,450MM,Shield)
BN81 CWB1C007200BM WIRE ASS'Y
BN84 CWB1B005080BM WIRE ASS'Y (5P,2.5MM,80MM)
BN85 CWB1B013200EN001 WIRE ASS'Y (13P,2.0MM,200MM,Shield)
BN88 CWB1B005100BM WIRE ASS'Y (5P,2.5MM,100MM)
BN89 CWB1B003080MM WIRE ASS'Y (3P,2.5MM,80MM)
CN72 CJP31GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 31P) MOLEX 52045-**45
CN84 CJP05GB03ZY WAFER , ANGLE (2.5mm)
CN85 CJP13GA19ZY WAFER, STRAIGHT, 13PIN
CN86 CJP02GA89ZM WAFER
CN88 CJP05GB03ZY WAFER , ANGLE (2.5mm)
C906 KCKDKS471ME CAP , CERAMIC(KH TYPE) DKS471ME
D701 CVD52CSBBCEAB2 L.E.D , BLUE
D703 CVD52CSBBCEAB2 L.E.D , BLUE
D705 CVD52CSBBCEAB2 L.E.D , BLUE
D727 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLUE) TOL-50BOBBWGA
D728 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLUE) TOL-50BOBBWGA
D778 HVD1N5819T DIODE , SCHOTTKY 1N5819
FIP2 CFL162BD01GINK V.F.D 162-BD-01GINK
IC73 HRVNJL34H380A SENSOR , REMOCON
IC75 HVI74ACT04MTR I.C , HEX
IC76 HVI74HCU04AFNG I.C , INVERTER TC74HCU04AFNG(TOSHIBA)
IC86 HVINJM4556AL I.C , HEADPHONE NJM4556AL
JK43 HJJ2D003Y JACK , HEADPHONE (SILVER)
JK81 CJJ4M041Y JACK , BOARD (COAX)
JK82 HJSTORX177L MODULE , OPTICAL(RX) TORX177L
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE)
JK86 CJJ4S023Y JACK , BOARD
SW1 CSH1A008ZV SW , PUSH (MOMS)
VR74 CSR2A037Z ENCODER
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
V
alue
CUAAVR142/230 BOTTOM CHASSIS ASS'Y
CHD1A012ZR SCREW , SPECIAL
CHD1A023R SCREW , SPECIAL
CHD4A012R SCREW , SPECIAL
CHE170 HOLDER , PCB
CHE36-3 CLAMPER , WIRE
CHG1A160Z CUSHION , RUBBER
CHG1A360 CUSHION , FOOT
CHR301 CLAMPER
CHS1A032 TAPE , HEMELON
CJA2B043ZA CORD , POWER(EUR) QDR-7100CC
CKL2A069H43 FOOT
CLT5U036ZE TRANS , MAIN AVR139/230
CNVM9004MS1J75L MODULE , TUNER EUR KST-M9004MS1-J75L(WO/19KHZ)
CTB3+10JFZR SCREW
CTB3+6FFZR SCREW
CTB3+8JFZR SCREW
CTW3+12JR SCREW
CUA2A294 CHASSIS , BOTTOM
KBA2C4000TLEY FUSE 4A/250V(EUR)
KHR1A028 BUSHING , AC CORD
CN12 CWC4C4A27B120B10 CABLE , CARD (11P,1.25MM,120MM,B,10MM)
CN13 CWC4C4A13B100B10 CABLE , CARD (13P,1.25MM,100MM,B,10MM)
CN14 CWC4C4A11B100B10 CABLE , CARD (11P,1.25MM,100MM,B,10MM)
CN45 CWC4F2A07A060B10 CABLE , CARD (7P,1.0MM,60MM,B,10MM)
CN83 CWB4F232450UU 2P WIRE ASS'Y
(
450MM UL1617
)
