Harman Kardon AVR 141/230

HDMI PCB ASSY
Ref. # Part Number
Description
V
alue
COP12109B HDMI MUX PCB ASS'Y
CN45 CJP07GA193ZY WAFER , CARD CABLE SMD
C637 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C901 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C903 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C904 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C905 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C906 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C907 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C908 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C909 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C910 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C911 CCUS1A105KC CAP , CHIP 1UF 10V K
C912 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C913 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C914 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C915 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C916 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C917 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C918 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C919 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C920 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C921 CCSJA0J220B CAP , CHIP TANTAL(A TYPE, 22uF/6.3V, ELNA)
C922 CCSJA0J220B CAP , CHIP TANTAL(A TYPE, 22uF/6.3V, ELNA)
C923 CCSJA0J220B CAP , CHIP TANTAL(A TYPE, 22uF/6.3V, ELNA)
C924 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C925 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C926 HCEC1CRV2220T CAP , CHIP ELECT 22UF/16V
C927 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C928 HCEC1CRV2220T CAP , CHIP ELECT 22UF/16V
C929 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C930 HCEC1CRV2220T CAP , CHIP ELECT 22UF/16V
IC91 CVISII9185ACTU I.C , HDMI RX SW(80PIN TQFP) SII9185ACTU
IC92 CVIKIA1117S50 I.C , REGULATOR(SOT-223) KIA1117S50-RTK/P
IC93 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223
IC94 CVIKIA1117S18 I.C , REGULATOR(SOT-223) KIA1117S/F18, SOT-223
JK81 HJJ9H003Z JACK , HDMI(JALCO) YKF45-7009
JK82 HJJ9H003Z JACK , HDMI(JALCO) YKF45-7009
JK83 HJJ9H003Z JACK , HDMI(JALCO) YKF45-7009
JK84 HJJ9H003Z JACK , HDMI(JALCO) YKF45-7009
L823 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI )
L824 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI )
L825 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI )
L826 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI )
L901 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60
L902 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30
L903 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60
Q901 HVTKRA102S T.R , CHIP KRA102S
Q902 CVTKRC103S T.R , CHIP
Q903 HVTKRA102S T.R , CHIP KRA102S
Q904 CVTKRC103S T.R , CHIP
Q905 HVTKRA102S T.R , CHIP KRA102S
Q906 CVTKRC103S T.R , CHIP
R901 CRJ10DJ102T RES , CHIP 1608 SIZE
R902 CRJ10DJ223T RES , CHIP 1608 SIZE
R911 CRJ10DJ102T RES , CHIP 1608 SIZE
R912 CRJ10DJ223T RES , CHIP 1608 SIZE
R915 CRJ10DJ473T RES , CHIP 1608 SIZE
R916 CRJ10DJ103T RES , CHIP 1608 SIZE
R921 CRJ10DJ102T RES , CHIP 1608 SIZE
R922 CRJ10DJ223T RES , CHIP 1608 SIZE
R932 CRJ10DJ473T RES , CHIP 1608 SIZE
R933 CRJ10DJ152T RES , CHIP 1608 SIZE
R934 CRJ10DJ152T RES , CHIP 1608 SIZE
R935 CRJ10DJ473T RES , CHIP 1608 SIZE
R936 CRJ10DJ473T RES , CHIP 1608 SIZE
R937 CRJ10DJ202T RES , CHIP
R938 CRJ10DJ202T RES , CHIP
R939 CRJ10DJ221T RES , CHIP 1608 SIZE
R940 CRJ10DJ221T RES , CHIP 1608 SIZE
R941 CRJ10DJ221T RES , CHIP 1608 SIZE
R963 CRJ10DJ473T RES , CHIP 1608 SIZE
R964 CRJ10DJ101T RES , CHIP 1608 SIZE
MAIN PCB ASSY
Ref. # Part Number
Description
V
alue
COP12186B AVR139/230 MAIN PCB ASS'Y
CHR301 CLAMPER
C501 CCEA1HH100T CAP , ELECT 10UF 50V
C502 CCEA1HH100T CAP , ELECT 10UF 50V
C503 CCEA1HH100T CAP , ELECT 10UF 50V
C504 CCEA1HH100T CAP , ELECT 10UF 50V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K
