Harman Kardon AVR 141/230

INPUT PCB ASSY
Ref. # Part Number
Description
V
alue
R761 CRJ10DJ104T RES , CHIP 1608 SIZE
R762 CRJ10DJ104T RES , CHIP 1608 SIZE
R763 CRJ10DJ472T RES , CHIP 1608 SIZE
R764 CRJ10DJ472T RES , CHIP 1608 SIZE
R765 CRJ10DJ103T RES , CHIP 1608 SIZE
R766 CRJ10DJ103T RES , CHIP 1608 SIZE
R767 CRJ10DJ301T RES , CHIP 1608
R768 CRJ10DJ562T RES , CHIP 1608 SIZE
R769 CRJ10DJ330T RES , CHIP 1608 SIZE
R770 CRJ10DJ330T RES , CHIP 1608 SIZE
R771 CRJ10DJ0R0T RES , CHIP 1608 SIZE
R773 CRJ10DJ332T RES , CHIP 1608 SIZE
R774 CRJ10DJ332T RES , CHIP 1608 SIZE
R775 CRJ10DJ332T RES , CHIP 1608 SIZE
R776 CRJ10DJ332T RES , CHIP 1608 SIZE
R777 CRJ10DJ102T RES , CHIP 1608 SIZE
R778 CRJ10DJ103T RES , CHIP 1608 SIZE
R779 CRJ10DJ102T RES , CHIP 1608 SIZE
R780 CRJ10DJ102T RES , CHIP 1608 SIZE
R781 CRJ10DJ750T RES , CHIP 1608 SIZE
R782 CRJ10DJ272T RES , CHIP 1608 SIZE
R783 CRJ10DJ272T RES , CHIP 1608 SIZE
R784 CRJ10DJ473T RES , CHIP 1608 SIZE
R785 CRJ10DJ104T RES , CHIP 1608 SIZE
R786 CRJ10DJ471T RES , CHIP 1608 SIZE
R787 CRJ10DJ101T RES , CHIP 1608 SIZE
R789 CRJ10DJ103T RES , CHIP 1608 SIZE
R790 CRJ10DJ103T RES , CHIP 1608 SIZE
R791 CRJ10DJ101T RES , CHIP 1608 SIZE
R793 CRJ10DJ103T RES , CHIP 1608 SIZE
R794 CRJ10DJ102T RES , CHIP 1608 SIZE
R795 CRJ10DJ102T RES , CHIP 1608 SIZE
R796 CRJ10DJ102T RES , CHIP 1608 SIZE
R799 CRJ10DJ102T RES , CHIP 1608 SIZE
R800 CRJ10DJ102T RES , CHIP 1608 SIZE
R801 CRJ10DJ105T RES , CHIP 1608 SIZE
R802 CRJ10DJ100T RES , CHIP 1608 SIZE
R803 CRJ10DJ101T RES , CHIP 1608 SIZE
R804 CRJ10DJ103T RES , CHIP 1608 SIZE
R805 CRJ10DJ330T RES , CHIP 1608 SIZE
R910 CRJ10DJ105T RES , CHIP 1608 SIZE
R932 CRJ10DJ103T RES , CHIP 1608 SIZE
R960 CRJ10DJ332T RES , CHIP 1608 SIZE
R963 CRJ10DJ105T RES , CHIP 1608 SIZE
R966 CRJ10DJ472T RES , CHIP 1608 SIZE
R992 CRJ10DJ562T RES , CHIP 1608 SIZE
X702 HOX27000E180S CRYSTAL , CHIP(27MHZ,SMD) HC-49/US
C261 CCEA1EH470T CAP , ELECT 47UF 25V
C262 CCEA1EH470T CAP , ELECT 47UF 25V
C263 CCEA1EH470T CAP , ELECT 47UF 25V
C264 CCEA1EH470T CAP , ELECT 47UF 25V
C265 CCEA1EH470T CAP , ELECT 47UF 25V
C266 CCEA1EH470T CAP , ELECT 47UF 25V
C267 CCEA1EH470T CAP , ELECT 47UF 25V
C268 CCEA1EH470T CAP , ELECT 47UF 25V
C272 CCEA1HH100T CAP , ELECT 10UF 50V
C273 CCEA1HH100T CAP , ELECT 10UF 50V
C275 CCEA1HH100T CAP , ELECT 10UF 50V
C276 CCEA1HH100T CAP , ELECT 10UF 50V
C281 CCEA1HH100T CAP , ELECT 10UF 50V
C282 CCEA1HH100T CAP , ELECT 10UF 50V
C283 CCEA1HH100T CAP , ELECT 10UF 50V
C284 CCEA1HH100T CAP , ELECT 10UF 50V
C285 CCEA1HH100T CAP , ELECT 10UF 50V
C286 CCEA1HH100T CAP , ELECT 10UF 50V
C292 CCEA1CH101T CAP , ELECT 100UF 16V
C294 CCEA1CH101T CAP , ELECT 100UF 16V
C341 CCEA1HH100T CAP , ELECT 10UF 50V
C342 CCEA1HH100T CAP , ELECT 10UF 50V
C343 CCEA1HH100T CAP , ELECT 10UF 50V
C344 CCEA1HH100T CAP , ELECT 10UF 50V
C345 CCEA1HH100T CAP , ELECT 10UF 50V
C346 CCEA1HH100T CAP , ELECT 10UF 50V
C358 CCEA1CH101T CAP , ELECT 100UF 16V
C360 CCEA1CH101T CAP , ELECT 100UF 16V
C371 CCEA1HH100T CAP , ELECT 10UF 50V
C372 CCEA1HH100T CAP , ELECT 10UF 50V
C373 CCEA1HH100T CAP , ELECT 10UF 50V
C374 CCEA1HH100T CAP , ELECT 10UF 50V
C375 CCEA1HH100T CAP , ELECT 10UF 50V
C376 CCEA1HH100T CAP , ELECT 10UF 50V
C389 CCEA1HH100T CAP , ELECT 10UF 50V
C390 CCEA1HH100T CAP , ELECT 10UF 50V
C600 CCEA1CH101T CAP , ELECT 100UF 16V
C602 CCEA1CH101T CAP , ELECT 100UF 16V
C604 CCEA1CH101T CAP , ELECT 100UF 16V
harman/kardon
AVR 139-141-142/230 Service Manual
Page 26 of 83
