Harman Kardon AVR 141/230

INPUT PCB ASSY
Ref. # Part Number
Description
V
alue
C606 CCEA1CH101T CAP , ELECT 100UF 16V
C608 CCEA1CH101T CAP , ELECT 100UF 16V
C610 CCEA1CH101T CAP , ELECT 100UF 16V
C612 CCEA1CH101T CAP , ELECT 100UF 16V
C614 CCEA1CH101T CAP , ELECT 100UF 16V
C616 CCEA1CH101T CAP , ELECT 100UF 16V
C618 CCEA1CH101T CAP , ELECT 100UF 16V
C620 CCEA1CH101T CAP , ELECT 100UF 16V
C622 CCEA1CH101T CAP , ELECT 100UF 16V
C624 CCEA1CH101T CAP , ELECT 100UF 16V
C626 CCEA1CH101T CAP , ELECT 100UF 16V
C628 CCEA1CH101T CAP , ELECT 100UF 16V
C630 CCEA1CH101T CAP , ELECT 100UF 16V
C703 CCEA1CH101T CAP , ELECT 100UF 16V
C706 CCEA1CH101T CAP , ELECT 100UF 16V
C717 CCEA1CH101T CAP , ELECT 100UF 16V
C720 CCEA1AH471T CAP , ELECT 470UF 10V
C721 CCEA1AH471T CAP , ELECT 470UF 10V
C724 CCEA1AH471T CAP , ELECT 470UF 10V
C726 CCEA1CH101T CAP , ELECT 100UF 16V
C728 CCEA1AH471T CAP , ELECT 470UF 10V
C730 CCEA1CH101T CAP , ELECT 100UF 16V
C736 CCEA1HH2R2T CAP , ELECT 2.2UF 50V
C737 CCEA1CH101T CAP , ELECT 100UF 16V
C740 CCEA1CH101T CAP , ELECT 100UF 16V
C749 CCEA1CH101T CAP , ELECT 100UF 16V
C764 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C766 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C767 CCEA1CKS100T CAP , ELECT 10UF 16V
C774 CCEA1CH101T CAP , ELECT 100UF 16V
C802 CCEA1HH100T CAP , ELECT 10UF 50V
D704 CVD1N4003SRT DIODE , RECT 1N4003
IC36 HVIKA78L08AZT I.C , REGULATOR (+8V) KA78LXXAZTA
IC37 HVIKA79L08AZT REGULATOR, -8V KA79LXXAZTA
CN10 CJP09GA01ZY CON WAFER YMW025-09R
CN12 CJP27GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 27P) MOLEX 52045-**45
CN13 CJP13GA115ZY WAFER , CARD CABLE
CN14 CJP11GA115ZY WAFER(11P, ST 1.25MM)
CN17 CJP06GB142ZB PIN HEADER(6P, 2.54mm)
CN19 CJP07GA117ZY WAFER
CN20 CJP07GA01ZY WAFER , STRAIGHT(7PIN)
CN72 CJP31GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 31P) MOLEX 52045-**45
C732 CCEA0JKR3222E CAP , ELECT
D703 CVD1N4003ST DIODE , RECT 1N4003
JK11 CJJ4R019W TERMINAL , IN/OUT
JK12 CJJ4P014W JACK , IN/OUT
JK13 CJJ4R019W TERMINAL , IN/OUT
JK14 CJJ4P043W JACK IN/OUT
JK78 CJJ4S022Z JACK , BOARD
X701 HOX24576E150TF CRYSTAL 24.576MHZ
X703 HOX04332E200C CRYSTAL
VIDEO PCB ASSY
Ref. # Part Number
Description
V
alue
COP12188B AVR139/230 VIDEO PCB ASS'Y
C101 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z
C102 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z
C103 CCFT1H473ZF CAP , CERAMIC 0.047UF 50V Z
C104 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C105 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C106 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C107 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C108 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C109 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C110 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C117 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C118 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C119 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C
C120 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C
C121 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C122 CCEA2AH101E CAP , ELECT
C401 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C402 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C403 CCEA1HH100T CAP , ELECT 10UF 50V
C404 CCEA1HH100T CAP , ELECT 10UF 50V
C405 CCEA1HH100T CAP , ELECT 10UF 50V
C406 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C407 CCEA1CH101T CAP , ELECT 100UF 16V
C408 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C409 CCEA1CH101T CAP , ELECT 100UF 16V
C410 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C411 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C412 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C601 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C602 CCEA0JH102T CAP , ELECT 1000UF 6.3V
