VIDEO PCB ASSY
Ref. # Part Number
Description
V
alue
C603 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C604 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C605 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C606 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C607 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C608 CCEA1HH100T CAP , ELECT 10UF 50V
C609 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C610 CCEA1HH100T CAP , ELECT 10UF 50V
C611 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C612 CCEA1HH100T CAP , ELECT 10UF 50V
C613 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C614 CCEA1HH100T CAP , ELECT 10UF 50V
C615 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C616 CCEA1HH100T CAP , ELECT 10UF 50V
C617 CCBS1H220JCT CAP , CERAMIC(22PF/50V) CH UP025CH220J-A-B Z
C618 CCEA1HH100T CAP , ELECT 10UF 50V
C619 CCEA1CH101T CAP , ELECT 100UF 16V
C620 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C621 CCEA1HH100T CAP , ELECT 10UF 50V
C623 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C624 CCEA1CH101T CAP , ELECT 100UF 16V
D101 HVDMTZJ5.1BT DIODE , ZENER MTZJ5.1B 1/2W
D102 HVDMTZJ27BT DIODE , ZENER MTZJ27B 1/2W
D105 CVD1N4003ST DIODE , RECT 1N4003
D106 CVD1N4003ST DIODE , RECT 1N4003
D108 CVD1N4003ST DIODE , RECT 1N4003
D109 CVDZJ6.8BT DIODE , ZENER ZJ6.8B 1/2W
D110 CVDZJ6.8BT DIODE , ZENER ZJ6.8B 1/2W
D111 CVD1N4003ST DIODE , RECT 1N4003
D112 CVD1N4003ST DIODE , RECT 1N4003
D113 CVD1N4003ST DIODE , RECT 1N4003
D114 CVD1N4003ST DIODE , RECT 1N4003
D401 CVDZJ5.1BT DIODE , ZENER ZJ5.1B 1/2W
D402 CVDZJ5.1BT DIODE , ZENER ZJ5.1B 1/2W
Q104 CVTKTC1027YT T.R
R101 CRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J
R108 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R109 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R110 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R111 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R112 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R113 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R121 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R122 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R401 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R402 CRD25TJ101T RES , CARBON
R403 CRD25TJ101T RES , CARBON
R411 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R421 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R451 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R461 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R491 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R601 CRD20TJ680T RES , CARBON 68 OHM 1/5W J
R602 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R603 CRD20TJ560T RES , CARBON 56 OHM 1/5W J
R604 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R605 CRD20TJ620T RES , CARBON 1/5W 62 OHM
R611 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R613 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R615 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R621 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R623 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R625 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R674 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R675 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN14 CJP11GA115ZY WAFER(11P, ST 1.25MM)
BN96 CWB1C009280BM WIRE ASS'Y (9P,2.5MM,280MM)
CN13 CJP05GA01ZY WAFER(YMW025-05R)
CN45 CJP07GA117ZY WAFER
CN81 CJP07GA01ZY WAFER , STRAIGHT(7PIN)
D103 HVD2A04H DIODE , RECT(2A)
D104 HVD2A04H DIODE , RECT(2A)
IC41 CVINJM2595MTE1 I.C , VIDEO S/W
IC61 CVINJW1321FP1 I.C , VIDEO S/W
IC62 HVIKIA7809API I.C , REGULATOR +9V KIA7809 (KEC)
JK10 CJJ4S010Z JACK , BOARD
JK12 CJJ4N043Z JACK , BOARD
JK13 CJJ4R045Z JACK , BOARD
JK14 CJJ4S030Z JACK , BOARD 3P,G/B/R,SILVER
R104 CRQ1AJR47H RES , FUSE
R105 CRQ1AJR47H RES , FUSE
R106 CRQ1AJR33H RES , FUSE
R107 CRQ1AJR33H RES , FUSE
