Model (continued) AVR 745 AVR 645 AVR 445 AVR 345 AVR 245 AVR 145

DSP Processor TI DA 610 TI DA 610 TI DA 610 Cirrus

CS 49510 Cirrus

CS 49510

Output DACs 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit 192kHz/24-bit

Video Processing/ DCDi

by Faroudja Composite/S to component Composite/S to component DCDi

by Faroudja Composite/S to component No

Conversion scaling to 720p or 1080i transcoding transcoding scaling to 720p transcoding

A/V Sync Delay 200 mS 80 mS 80 mS 80 mS 80 mS 80 mS

IEC Detachable Power Cord Yes Yes Yes Yes No No

System Remote TC 30 activity-based, 9-Device learning & 9-Device learning & 11-Device programmable 11-Device programmable 8-Device programmable

color LCD, Internet programmability programmable with backlit, programmable with backlit,

two-line LCD two-line LCD

IR-In/Out Jacks Yes Yes Yes Yes Yes No

IR Carrier Output Yes Yes Yes Yes No No

Discrete Remote-On/Off Codes Yes Yes Yes Yes Yes Yes

Low-Voltage Trigger Jacks 2 1 1 No No No

External Data Port USB and RS-232 USB and RS-232 USB and RS-232 RS-232 RS-232 RS-232

Speaker Terminals All-metal color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts Color-coded binding posts

Dimensions

6-1/2" x 17-5/16" x 17-1/16" 6-1/2" x 17-5/16" x 17-1/16" 6-1/2" x 17-5/16" x 17-1/16" 6-1/2" x 17-5/16" x 15" 6-1/2" x 17-5/16" x 15" 6-1/2" x 17-5/16" x 15"

(H x W x D)

Weight 52 lb 41 lb 39 lb 34 lb 30 lb 24.4 lb

Model AVR 745 AVR 645 AVR 445 AVR 345 AVR 245 AVR 145

Description 7.2-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 7.1-Channel AVR 5.1-Channel AVR

Stereo Power (FTC) 100 x 2 90 x 2 80 x 2 70 x 2 65 x 2 50 x 2

Multichannel Power (FTC) 85 x 7* 75 x 7* 65 x 7* 55 x 7* 50 x 7* 40 x 5*

Amplifier Type High current High current High current High current High current High current

±60 amps ±50 amps ±40 amps ±35 amps ±35 amps ±25 amps

THD @ Impedance 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms 0.07% @ 8 ohms

Bandwidth 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz 20Hz – 20kHz

Bandwidth @ 1W 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz 10Hz – 130kHz

(+0dB/–3dB)

Signal-to-Noise Ratio (IHF-A) 100dB 100dB 100dB 100dB 100dB 100dB

Power Supply Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear Independent front & rear

Dolby

Digital Dolby

Digital EX Dolby

Digital EX

Dolby

Pro Logic

II Pro Logic

IIx Pro Logic

IIx

Dolby

Virtual Speaker Yes Yes Yes Yes Yes No

DTS

5.1 Yes Yes Yes Yes Yes Yes

DTS-ES

6.1 Yes Yes Yes Yes Yes Yes

Discrete & Matrix

DTS 96/24

Yes Yes Yes Yes Yes Yes

DTS Neo:6

Yes Yes Yes Yes Yes Yes

Logic 7

Yes Yes Yes Yes Yes Yes

Headphone Modes 2-Channel, Dolby

HP 2-Channel, Dolby

XM-Ready

Yes Yes Yes Yes Yes No

Multizone Capability Audio/video, with remote Audio,with remote Audio, with remote Audio, with remote Audio No

Assignable Rear-Channel Yes Yes Yes Yes Auto assignment No

Amplifiers for multizone

A-BUS/

READY

®1

Yes Yes Yes Yes No No

EzSet

Capability EzSet/EQ II EzSet/EQ EzSet/EQ EzSet/EQ EzSet+ EzSet remote

A/V Inputs 5 5 5 5 5 4

S-Video Inputs 5 5 5 5 5 4

Analog Audio Inputs 4 4 4 4 4 4

Digital Audio Inputs Rear panel 3/3/1 Rear panel 3/3/1 Rear panel 3/3/1 Rear panel 3/3/0 Rear panel 2/2/0 Rear panel 2/2/0

(Coax/Optical/USB

) Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0 Front panel 1/1/0

Digital Audio Outputs Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1 Rear panel 1/1

(Coax/Optical) Front panel 1/0 Front panel 1/0

Digital Input Polling All sources

All sources

Direct Audio Inputs 7.1 With bass management 7.1 7.1 7.1 7.1 5.1

HDMI

™

Inputs/Output 2/1 2/1 2/1 2/1 2/1 0

HDMI

™

Type 1.1 With audio/video processing 1.1 With audio processing Switching 1.1 With audio/video processing Switching N/A

Preamp Outputs 7.2 Channels 7.1 Channels 7.1 Channels 7.1 Channels 7.1 Channels Subwoofer

Component Video 3 @ 100MHz 2 @ 60MHz 2 @ 60MHz 3 @ 100MHz 3 @ 100MHz 2 @ 100MHz

Inputs (Assignable)

Bass Management Quad crossover Quad crossover Quad crossover Quad crossover Quad crossover Triple crossover

On-Screen Display Yes, including component Yes, including component Yes, including component Yes, including component Yes Yes

Input Titling All inputs except tuner All inputs except tuner All inputs except tuner All inputs except tuner All inputs except tuner All inputs except tuner

* All channels operating at full power.

1: Optional XM antenna module and subscription to XM service required. Hardware and service sold separately. XM service is not available in Alaska or Hawaii.

2: USB port is compatible only with PCs running either Microsoft

Windows

2000 with Service Pack 4 or higher or Windows XP with Service Pack 1 or higher.

3: Except tuner, The Bridge/DMP, XM Radio and 6-/8-channel sources.

SPECIFICATIONS

46 47

Model HKTS 18 HKTS 15 HKS 9 HKS 6

Satellites 4 Identical 2-way satellites with dual 3" midranges 4 Identical 2-way satellites with 3" midrange 2 Identical 2-way satellites with dual 3" midranges 2 Identical 2-way satellites with 3" midrange

3/4"-dome tweeter, video-shielded and 1/2"-dome tweeter, video-shielded and 3/4"-dome tweeter, video-shielded and 1/2"-dome tweeter, video-shielded

Center Channel Speaker Voice-matched with dual 3" Voice-matched with dual 3" N/A N/A

midranges and 3/4"-dome tweeter midranges and 3/4"-dome tweeter

Subwoofer 200-Watt,bass-reflex powered 100-Watt,bass-reflex powered

N/A N/A

subwoofer with 10" driver;external trgger input subwoofer with 10" driver;external trgger input

Nominal Impedance 8 Ohms (sats & center) 8 Ohms (sats & center) 8 Ohms 8 Ohms

Sensitivity (SPL @ 1 Watt/Meter) 86dB (sats & center) 86dB (sats & center) 86dB 86dB

Frequency Response System:25Hz – 20kHz (–6dB) System:35Hz – 20kHz (–6dB) 105Hz – 20kHz (–6dB) 110Hz – 20kHz (–6dB)

Line-Level Inputs Stereo RCA jacks and dedicated LFE Stereo RCA jacks and dedicated LFE N/A N/A

Speaker-Level Inputs & Outputs Binding posts Binding posts Spring lever (inputs only) Spring lever (inputs only)

Recommended Amplifier Power 10W – 120W 10W – 80W 10W – 120W 10W – 80W

Subwoofer Level Control Yes Yes N/A N/A

Phase Switch Yes Yes N/A N/A

Audio Sense Turn-On Yes Yes N/A N/A

Low-Pass Filter Switch Yes Yes N/A N/A

Cables Included Yes Yes Yes Yes

Wall-Mount Capability Brackets included for 4 satellites Brackets included for 4 satellites Pair of brackets included Pair of brackets included

Dimensions (H x W x D) Sats:9-9/16" x 3-15/16" x 3-5/8" Sats: 6-9/16" x 3-15/16" x 3-5/8" 9-9/16" x 3-15/16" x 3-5/8" 6-9/16" x 3-15/16" x 3-5/8"

Center:4" x 9-1/2" x 3-5/8" Center: 4" x 9-1/2" x 3-5/8"

Sub: 18-7/8" x 13-3/8" x 13-3/8" Sub: 18-7/8" x 13-3/8" x 13-3/8"

Weight Sats: 2.8 lb; Center: 2.7 lb;Sub:35 lb Sats:1.7 lb; Center:2.7 lb; Sub:35 lb 2.8 lb 1.7 lb

Finish Black lacquer Black lacquer Black lacquer Black lacquer

NOTE: Depth measurements include knobs, buttons and terminal connections;height measurements include feet and chassis.All features and specifications are subject to change without notice.

Harman Kardon, Harman International,EzSet, (patent no.5,386,478), EzSet+, , Lexicon,Logic 7, and VMAx (an implementation of Cooper Bauck Transaural Stereo under patent license) are trademarks of Harman International Industries,

Incorporated, registered in the United States and/or other countries. Designed to Entertain, , EzSet EQ, and Drive+Play are trademarks of Harman International Industries, Incorporated.

A-BUS and A-BUS/

READY

are registered trademarks of LeisureTech Electronics Pty Ltd.Australia. Burr-Brown is a trademark of Texas Instruments. Cirrus is a registered trademark of Cirrus Logic,Inc.DCDi by Faroudja is a registered trademark of Genesis Microchip Inc.

DivX is a registered trademark of DivX, Inc. Dolby and Pro Logic are registered trademarks of Dolby Laboratories. DTS, DTS-ES, DTS 96/24 and DTS Neo:6 are registered trademarks of DTS, Inc. HDCD (High Definition Compatible Digital),Microsoft,Windows and Windows Media

are registered trademarks of Microsoft Corporation in the United States and/or other countries. Gracenote is a registered trademark of Gracenote,Inc.HDMI (High-Definition Multimedia Interface) is a trademark of HDMI Licensing LLC. Intel is a registered trademark of Intel Corporation.

iPod and Mac OS are registered trademarks, and Shuffle is a trademark,of Apple Computer, Inc. Kodak is a registered trademark of Eastman Kodak Company. SACD (Super Audio CD) is a trademark of Sony Corporation.ThumbDrive is a trademark of Trek 2000 International Limited.
