Harman Kardon AVR 147

9
Surround Mode
Tuning
Preset Stations
Surround Select
Tuner Band
Tuning Mode
Source Input Select
Headphone Jack/EzSet/EQ Microphone Input
Digital Audio Inputs (Optical 3/Coaxial 3)
Video 3 Video Inputs
Video 3 Analog Audio Inputs
Navigation
Tone Mode
Speaker Size Setup
Delay
Digital Input Select
Remote IR Sensor
Power Indicator
Main Power Switch
Standby/On Switch
Volume
Source Indicators
Message Display
Surround Mode Indicators
Speaker/Channel Input Indicators
Channel Level Adjust
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
