Audio Specifications| stereo power | 75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD |
|---|---|
| multichannel power | 75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD |
| input sensitivity/impedance | 250mV/27k ohms |
| signal-to-noise ratio (IHF-A) | 75dB |
| frequency response (@ 1W) | 10Hz – 130kHz (+0dB/–3dB) |
| high instantaneous current capability (HCC) | ±25 amps |
| slew rate | 40V/sec |
FM Tuner Specifications| frequency range | 87.5MHz – 108.0MHz |
|---|---|
| usable sensitivity IHF | 1.3µV/13.2dBf |
| signal-to-noise ratio (mono/stereo) | 70dB/68dB |
| distortion (mono/stereo) | 0.2%/0.3% |
| stereo separation | 40dB @ 1kHz |
| selectivity (±400kHz) | 70dB |
AM Tuner Specifications| frequency range | 520kHz – 1, 510kHz |
|---|---|
| signal-to-noise ratio | 38dB |
| usable sensitivity (loop) | 375µV |
| distortion (1kHz, 50% mod) | 1.0% |
| selectivity (±10kHz) | 30dB |
Video Specifications| television format | NTSC |
|---|---|
| input level/impedance | 1Vp-p/75 ohms |
| output level/impedance | 1Vp-p/75 ohms |
| video frequency response (composite video) | 10Hz – 8MHz (–3dB) |
| HDMI | Supports up to 4K x 2K |
General Specifications| power requirement | 120V AC / 60Hz |
|---|---|
| power consumption | <0.5W (standby); 410W maximum |
| dimensions (H x W x D) | 4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm) |
| weight | 10 lb (4.6kg) |
