AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

...3 COP12502H AVR1510 FRONT PCB ASS'Y 1

.......7 R1511 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1512 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1513 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1514 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1515 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1516 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1517 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1518 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1519 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1522 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1523 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1524 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1529 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1530 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1531 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1532 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1533 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1534 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1535 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1536 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1537 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1540 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1541 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1542 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1547 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1548 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1549 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1550 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1551 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1552 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1553 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7

R1554 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1555 CRJ10DJ102T RES, CHIP(1608/5%/1Kohm) 00200-0094 1

.......7 R1556 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1557 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1558 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1559 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1560 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1561 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1562 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1565 CRJ10DJ102T RES, CHIP(1608/5%/1Kohm) 00200-0094 1

.......7 R1566 CRJ10DJ302T RES, CHIP(1608/5%/3Kohm) 1608 1

.......7 R1567 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1569 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1570 CRJ10DF1002T RES, CHIP(1608/1%/10Kohm) 10K /1/10W/F 1

.......7 R1571 CRJ10DF1002T RES, CHIP(1608/1%/10Kohm) 10K /1/10W/F 1

AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

...3 COP12502H AVR1510 FRONT PCB ASS'Y 1

.......7 R1572 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

......6

CIP12503ITSMD

AVR151/230 DIGITAL PCB TOP SMD ASS'Y (EUR) 1

.......7 CUP12503Z PCB,AVR1510 DIGITAL (FR-4/4L/206X135) 1

.......7 BN1401 CJP03GA208ZY WAFER , SMD (2MM PITCH)-3P 1

.......7 CN1001 CJP07GA193ZY WAFER, FFC, SMD(07P-1mm, STRAIGHT) 1

.......7 CN1101 CJP07GA208ZY WAFER, 2mm, SMD, Vertical, 07p 1

.......7 CN1201 CJP15GB276ZY WAFER, 20037WR-NN Series, 2mm, SMD, ANGLE, 15P 1

.......7 CN1401 CJP03GA208ZY WAFER , SMD (2MM PITCH)-3P 1

.......7 CN1402 CJP07GA193ZY WAFER, FFC, SMD(07P-1mm, STRAIGHT) 1

.......7 CN1403 CJP09GA193ZY WAFER, FFC, SMD(09-1mm, STRAIGHT) 1

.......7 C1001 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1002 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1003 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1004 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1005 CCUC0J106KC CAP, CHIP(2012, 6.3V/10uF, X7R) LAO-63V103MS56PW# 1

.......7 C1006 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1007 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1050 CCUS1H120JA CAP, CHIP(1608, 50V/12pF) 1

.......7 C1051 CCUS1H120JA CAP, CHIP(1608, 50V/12pF) 1

.......7 C1052 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1103 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1104 CCUS1H102KC CAP, CHIP(1608, 50V/1000pF) 1

.......7 C1106 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1107 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1109 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1110 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

.......7 C1111 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

.......7 C1112 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1115 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

.......7 C1116 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1117 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1118 CCUI1C104KC CAP, CHIP(1005, 16V/0.1uF) 1

.......7 C1122 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

.......7 C1123 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

.......7 C1124

CCEC1CMVG100T

CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1

.......7 C1126

CCEC1CMVG100T

CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1

.......7 C1127 CCUS0J225KC CAP, CHIP(1608, 6.3V/2.2uF) 1

.......7 C1128 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1

Harman Kardon

AVR 151 Service Manual

Page 23 of 131

Other manuals for Harman Kardon AVR 1510

Owner's Manual47 pages

Quick Start Guide11 pages

Manual3 pages

Questions and Answers:

Need help?

Do you have a question about the Harman Kardon AVR 1510 and is the answer not in the manual?

Harman Kardon AVR 1510 Specifications

Audio Specifications

stereo power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
multichannel power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	75dB
frequency response (@ 1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±25 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @ 1kHz
selectivity (±400kHz)	70dB

AM Tuner Specifications

frequency range	520kHz – 1, 510kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	375µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI	Supports up to 4K x 2K

General Specifications

power requirement	120V AC / 60Hz
power consumption	<0.5W (standby); 410W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10 lb (4.6kg)

View in Manual
