Harman Kardon AVR 155

BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
Value
CKF6A337Z PANEL , REAR AVR155/230 PANEL
CKL1A094 FOOT , A AVR350 FOOT
CKL1A095 FOOT , B AVR350 FOOT
CMD2A487 BRACKET , TRANS BRACKET
CNVM9004MS1J73L TUNER , EUR MODULE TUNER MODULE
CTB3+10JFZR SCREW SCREW
CTB3+6FFZR SCREW SCREW
CTB3+6JR SCREW SCREW
CTB3+8JR SCREW SCREW
CTS3+8JFZR SCREW SCREW
CTW3+12JR SCREW SCREW
CTW3+8JR SCREW SCREW
CUA3A229 CHASSIS , BOTTOM AVR350/230 CHASSIS
KHR1A028 BUSHING , AC CORD BUSHING
BN90 CSHAVR155ZA MOMS SW ASS'Y SW ASS'Y
CSH1A009ZV SWITCH , MOMS SWITCH
CWZAVR255ZA WIRE , ASS'Y(2P,150mm) WIRE
CB11 CWC4F2A13A100B CABLE , CARD(13P, 100mm) CARD CABLE
CB12 CWC1C4A21B110B CABLE , CARD CARD CABLE
CB13 CWC4C4A13B100B CABLE , CARD CARD CABLE
CB14 CWC4F2A13A100B CABLE , CARD(13P, 100mm) CARD CABLE
CB19 CWC4F2A07A080B CABLE , CARD(7P, 80mm, B TYPE) CARD CABLE
CB45 CWC4F2A07A080B CABLE , CARD(7P, 80mm, B TYPE) CARD CABLE
CB47 CWC4F2A07A120B CABLE , CARD (7P, 120MM, 1MM) CARD CABLE
F901 KBA2C4000TLEZ FUSE(233TYPE, 4A,250V) LITTEL FUSE
T901 CLT5V045ZE TRANS , POWER MAIN(AVR145/230) AVR145/230
FRONT PCB ASSY
Ref. # Part Number
Description
Value
CUP12024Z PCB , FRONT AVR155(330X163, FR-1) PCB
C714 CCBS1H151KBT CAP , CERAMIC(150PF/50V) 150UF 50V K
C716 CCEA1AH331T CAP , ELECT 330UF 10V
C719 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C720 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C721 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C723 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C728 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) 0.047UF 50V Z
C735 CCEA1CKS100T CAP , ELECT 10UF 16V
C742 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 2200PF 16V
C793 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C794 CCBS1C222MXT CAP , CERAMIC(2200PF/16V) 2200PF 16V
C795 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C796 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) 1000PF 50V K
C805 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C806 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C807 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C808 CCBS1H181KBT CAP , CERAMIC(180PF/50V) 180PF 50V
C809 CCEA1AH471T CAP , ELECT 470UF 10V
C812 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C817 CCBS1H100JCT CAP , CERAMIC(10PF/50V) 10PF 50V
C820 CCEA1HH100T CAP , ELECT 10UF 50V
C821 CCEA1EH470T CAP , ELECT 47UF 25V
C822 CCEA1EH470T CAP , ELECT 47UF 25V
C823 CCEA1HH100T CAP , ELECT 10UF 50V
C824 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C825 CCBS1H151KBT CAP , CERAMIC(150PF/50V) 150PF 50V
C828 CCBS1H470JT CAP , CERAMIC(47PF/50V) 47PF 50V
C830 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) 0.047F 50V
C841 CCEA1HH100T CAP , ELECT 10UF 50V
C842 CCEA1HH100T CAP , ELECT 10UF 50V
C843 CCEA1HH100T CAP , ELECT 10UF 50V
C850 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C851 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C852 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C856 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C857 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C862 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C863 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
harman/kardon
AVR 155/230 Service Manual
Page 10 of 92
