Harman Kardon AVR 155

AVR155/230 Electrical Parts List
Ref. # Part Number
Description
Value
CGB1A192Z BADGE , AVR155 BADGE
CGL1A222 INDICATOR , VOLUME INDICATOR
CGU1A318Y ORNAMENT , VOLUME AVR255 ORNAMENT
CGU1A410A25T WINDOW , FIP WINDOW
CGX1A338MBC63 CAP , VOLUME CAP
CGX1A390C66Y SHEET , AL FRONT AVR155 SHEET
CHE36-3 CLAMPER , WIRE CLAMPER
CKC6B145S60 CABINET , TOP AVR350 CABINET
CMH1A214 HOLDER , VOLUME HOLDER
CMZ1A127 FILTER , FIP AVR255 FILTER
CMZ2A090 SHEET , VOLUME SHEET
CQB1A549Y LABEL , ATTENTION DVD48 LABEL
CQB1A551Z LABEL , BAR CODE LABEL
CQB1A622 LABEL , SERIAL NO LABEL
CTB3+8JFZR SCREW SCREW
CTB4+6FFZR SCREW SCREW
CHE154 CLAMPER , ARM CLAMPER
CJXAVR340MICRO MICRO PHONE ASS'Y ASS'Y
CPG1A855W BOX , OUT CARTON AVR155/230 BOX
CQB1A551Z LABEL , BAR CODE LABEL
CQB1A876Z LABEL , COUNTRY DVD29/230 LABEL
CQS1A001 RIBON , BAR CODE SONY(TR-4070)
CQXAVR155/230 INSTRUCTION MANUAL ASS'Y ASS'Y
CARTAVR155/230 REMOCON TRANSMITTER ASS'Y REMOCON
CGRAVR350/230ZA COVER ASS'Y COVER ASS'Y
CGR2A436 COVER , A AVR350 COVER A
CGR2A437 COVER , B AVR350 COVER B
CGX1A391C66 ORNAMENT , AL A AVR350 ORNAMENT
CGX1A392C66 ORNAMENT , AL B AVR350 ORNAMENT
CQX1A1317Y MANUAL , INSTRUCTION AVR155/230 MANULAL
CQX1A1320Z MANUAL , SETUP AVR155/230 MANULAL
CSA1A018Z FM 1 POLE ANT FM ANT
CSA1A020Z ANT , AM LOOP AM ANT
FRONT PANEL ASSY
Ref. # Part Number
Description
Value
CGWAVR155/230 FRONT PANEL ASS'Y ASS'Y
CBT2A1057 KNOB , TUNING AVR350 KNOB
CBT3A1056 KNOB , STANDBY AVR155 KNOB
CGB1A158Y BADGE , FRONT HARMAN/KARDON BADGE
CGL1A265Y INDICATOR , POWER AVR155 INDICATOR
CGW2A440RHWB24 PANEL , FRONT AVR350/230 PANEL
CHR301 CLAMPER CLAMPER
CHS1A032 TAPE , HEMELON TAPE
CHS1A165 TAPE , HEMELON TAPE
CMC1A323 PLATE , SHIELD AVR350 PLATE
CMC2A326 PLATE , EARTH AVR350 PLATE
CMC2A338 PLATE , EARTH AVR350 PLATE
CMD2A443 BRACKET , SIDE BRACKET
CMH2A215 HOLDER , LED AVR350 HOLDER
CPE1A009 SHEET , BLIND SHEET
CTB3+10JR SCREW SCREW
CTWS3+10GR SCREW SCREW
CB72 CWC4F2A17A250B CABLE , CARD(17P, 1MM, 250MM) CRAD CABLE
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
Value
CUAAVR155/230 BOTTOM CHAASIS ASS'Y ASS'Y
CHD1A012ZR SCREW , SPECIAL SCREW
CHD1A023R SCREW , SPECIAL SCREW
CHD4A012R SCREW , SPECIAL SCREW
CHE170 HOLDER , PCB HOLDER
CHE36-3 CLAMPER , WIRE CLAMPER
CHG1A104Z CUSHION , RUBBER CUSHION
CHG1A160Z CUSHION , RUBBER CUSHION
CHG1A373 CUSHION , FOOT AVR350 CUSHION
CHS1A032 TAPE , HEMELON TAPE
CJA2B043WA CORD , POWER CRX-E320/G(1.8M, FERRITE) H03VVH2-F 2X0.75MM2 BK
CKF6A337Y PANEL , REAR AVR155/230 PANEL
harman/kardon
AVR 155/230 Service Manual
Page 9 of 92
