Harman Kardon AVR 155

FRONT PCB ASSY
Ref. # Part Number
Description
Value
S707 HST1A020ZT SW , TACT TACT SWITCH
S708 HST1A020ZT SW , TACT TACT SWITCH
S709 HST1A020ZT SW , TACT TACT SWITCH
S710 HST1A020ZT SW , TACT TACT SWITCH
S711 HST1A020ZT SW , TACT TACT SWITCH
S712 HST1A020ZT SW , TACT TACT SWITCH
S713 HST1A020ZT SW , TACT TACT SWITCH
S714 HST1A020ZT SW , TACT TACT SWITCH
S715 HST1A020ZT SW , TACT TACT SWITCH
S716 HST1A020ZT SW , TACT TACT SWITCH
S717 HST1A020ZT SW , TACT TACT SWITCH
S718 HST1A020ZT SW , TACT TACT SWITCH
S719 HST1A020ZT SW , TACT TACT SWITCH
S720 HST1A020ZT SW , TACT TACT SWITCH
CMC2A325 PLATE , EARTH AVR155 PLATE
BK71 CMD1A209 BRACKET , FLT BRACKET
BK72 CMD1A209 BRACKET , FLT BRACKET
BN10 CWZAVR155BN10 SHIELD WIRE ASS'Y(5P, 2MM, 350MM) WIRE
BN18 CWZAVR155BN18 SHIELD WIRE ASS'Y (5P, 350MM, 2MM PITCH) WIRE
BN22 CWZAVR155BN22 WIRE ASS'Y(7P, 2MM, 500MM) WIRE
BN41 CWZAVR155BN41 SHIELD WIRE ASS'Y(7P, 2MM, 500MM) WIRE
BN81 CWB1C907200BM WIRE ASS'Y WIRE
BN84 CWB2B905080EN WIRE ASS'Y WIRE
BN85 CWB2B903100EN WIRE ASS'Y WIRE
BN88 CWB2B905050EN WIRE ASS'Y WIRE
BN92 CWB2B905100EN WIRE ASS'Y WIRE
CN72 CJP17GA117ZY WAFER WAFER
CN84 CJP05GB46ZY WAFER WAFER
CN85 CJP03GA19ZY WAFER , STRAIGHT(3PIN) WAFER
CN88 CJP05GA19ZY WAFER , STRAIGHT WAFER
CN92 CJP05GA19ZY WAFER , STRAIGHT WAFER
D701 CVD1L0345W31BOCT20 L.E.D , WHITE CVD1L0345W31BOCT201
D703 CVD1L0345W31BOCT20 L.E.D , WHITE CVD1L0345W31BOCT201
D705 CVD1L0345W31BOCT20 L.E.D , WHITE CVD1L0345W31BOCT201
D723 CVD30ASOGCAA-S7 L.E.D , ORANGE T0L-30ASOGCAA-S7
D727 CVD1L0345W31BOCT20 L.E.D , WHITE CVD1L0345W31BOCT201
D778 HVD1N5819T DIODE , SCHOTTKY 1N5819
ET03 CMD1A629 BRACKET , PCB BRACKET
FIP1 CFL17BT031GINK F.I.P , AVR355 FIP(FUTABA,17BT031GINK)
IC73 HRVNJL34H380A SENSOR , REMOCON SENSOR
IC75 HVI74ACT04MTR I.C , HEX JRC(74ACT04MTR)
IC76 HVI74HCU04AFNG I.C , INVERTER FAIRCHILD(74HCU04AFNG)
IC86 HVINJM4556AL I.C , HEADPHONE JRC(NJM4556AL)
IC87 HVINJM2068MTE1 I.C , OP AMP JRC(NJM2068MTE1)
JK81 CJJ4M041Y JACK , BOARD (COAX) JACK
JK82 HJSTORX177L MODULE , OPTICAL(RX) OPT JACK
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) JACK
JK85 CJJ9M004Y JACK , S-VHS (SILVER) JACK
JK86 CJJ4S028Y JACK , BOARD (3P SILVER) JACK
JW83 CWE8202150RV WIRE ASS'Y WIRE
JW84 CWE8202150RV WIRE ASS'Y WIRE
JW88 CWE8202150RV WIRE ASS'Y WIRE
RL45 CSL4A016ZU RELAY , 12V 2C2P RELAY
VR74 CSR2A037Z ENCODER ENCODER
MAIN PCB ASSY
Ref. # Part Number
Description
Value
CHD3A012R SCREW , SPECIAL ASS'Y
CUP12026Y PCB , MAIN AVR245(330X247, FR/1) PCB
C501 CCEA1HH100T CAP , ELECT 10UF 50V
C502 CCEA1HH100T CAP , ELECT 10UF 50V
C503 CCEA1HH100T CAP , ELECT 10UF 50V
C504 CCEA1HH100T CAP , ELECT 10UF 50V
C505 CCEA1HH100T CAP , ELECT 10UF 50V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K
C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V K
C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C561 CCEA1CH101T CAP , ELECT 100UF 16V
harman/kardon
AVR 155/230 Service Manual
Page 13 of 92
