Harman Kardon AVR 155

MAIN PCB ASSY
Ref. # Part Number
Description
Value
C562 CCEA1CH101T CAP , ELECT 100UF 16V
C564 CCEA1CH101T CAP , ELECT 100UF 16V
C565 CCEA1CH101T CAP , ELECT 100UF 16V
C566 CCEA1CH101T CAP , ELECT 100UF 16V
C567 CCEA1CH101T CAP , ELECT 100UF 16V
C568 CCEA1CH101T CAP , ELECT 100UF 16V
C569 CCEA1CH101T CAP , ELECT 100UF 16V
C570 CCEA1CH101T CAP , ELECT 100UF 16V
C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C573 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C574 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C575 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V J
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V J
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V J
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V J
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V J
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V J
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V J
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V J
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V J
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V J
C681 CCEA1HH100T CAP , ELECT 10UF 50V
C682 CCEA1HH100T CAP , ELECT 10UF 50V
C683 CCEA1HH100T CAP , ELECT 10UF 50V
C684 CCEA1HH100T CAP , ELECT 10UF 50V
C685 CCEA1HH100T CAP , ELECT 10UF 50V
C726 CCKT1H221KB CAP , CERAMIC 220PF 50V K
C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C905 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C907 CCEA1CH101T CAP , ELECT 100UF 16V
C908 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C911 CCEA1CH471T CAP , ELECT 470UF 16V
C912 CCEA1EH221T CAP , ELECT 220UF 25V
C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C924 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C939 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C940 CCEA1AH471T CAP , ELECT 470UF 10V
C948 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C977 CCEA1HH3R3T CAP , ELECT 3.3UF 50V
C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C991 CCEA1HH1R0T CAP , ELECT 1UF 50V
C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C999 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z
D501 CVD1SS133MT DIODE 1SS133
D502 CVD1SS133MT DIODE 1SS133
D503 CVD1SS133MT DIODE 1SS133
D504 CVD1SS133MT DIODE 1SS133
D505 CVD1SS133MT DIODE 1SS133
D581 CVD1SS133MT DIODE 1SS133
D582 CVD1SS133MT DIODE 1SS133
D583 CVD1SS133MT DIODE 1SS133
D584 CVD1SS133MT DIODE 1SS133
D585 CVD1SS133MT DIODE 1SS133
D901 CVD1N4003SRT DIODE , RECT 1N4003
D902 CVD1SS133MT DIODE 1SS133
D911 CVD1SS133MT DIODE 1SS133
harman/kardon
AVR 155/230 Service Manual
Page 14 of 92
