Harman Kardon AVR 155

MAIN PCB ASSY
Ref. # Part Number
Description
Value
D912 CVD1SS133MT DIODE 1SS133
D914 CVD1SS133MT DIODE 1SS133
D917 CVD1SS133MT DIODE 1SS133
D953 CVD1SS133MT DIODE 1SS133
D954 CVD1N4003SRT DIODE , RECT 1N4003
D955 CVD1N4003SRT DIODE , RECT 1N4003
D956 CVD1N4003SRT DIODE , RECT 1N4003
D957 CVD1N4003SRT DIODE , RECT 1N4003
D961 CVD1N4003ST DIODE , RECT 1N4003
D962 CVD1N4003SRT DIODE , RECT 1N4003
D963 CVD1N4003SRT DIODE , RECT 1N4003
D973 CVD1SS133MT DIODE 1SS133
D974 CVD1SS133MT DIODE 1SS133
D979 CVDZJ5.1BT DIODE , ZENER ZJ5.1B 1/2W
ET90 HJT1A025 PALTE , EARTH MET37-0002
ET91 HJT1A025 PALTE , EARTH MET37-0002
F901 KJCFC5S HOLDER , FUSE HOLDER
F902 KBA2D2500TLET FUSE(SR-5,2.5A,250V) SAVE FUSETECH
IC97 HVIRE5VT28CATZ I.C , RESET RICOH(RE5VT28CATZ)
Q501 HVTKTA1268GRT T.R KTA1268GR
Q502 HVTKTA1268GRT T.R KTA1268GR
Q503 HVTKTA1268GRT T.R KTA1268GR
Q504 HVTKTA1268GRT T.R KTA1268GR
Q505 HVTKTA1268GRT T.R KTA1268GR
Q511 HVTKTC3200GRT T.R KTC3200GR
Q512 HVTKTC3200GRT T.R KTC3200GR
Q513 HVTKTC3200GRT T.R KTC3200GR
Q514 HVTKTC3200GRT T.R KTC3200GR
Q515 HVTKTC3200GRT T.R KTC3200GR
Q516 HVTKTC3200GRT T.R KTC3200GR
Q517 HVTKTC3200GRT T.R KTC3200GR
Q518 HVTKTC3200GRT T.R KTC3200GR
Q519 HVTKTC3200GRT T.R KTC3200GR
Q520 HVTKTC3200GRT T.R KTC3200GR
Q541 HVTKTC3198YT T.R KTC3198Y
Q542 HVTKTC3198YT T.R KTC3198Y
Q543 HVTKTC3198YT T.R KTC3198Y
Q544 HVTKTC3198YT T.R KTC3198Y
Q545 HVTKTC3198YT T.R KTC3198Y
Q556 HVTKTC3200GRT T.R KTC3200GR
Q557 HVTKTC3200GRT T.R KTC3200GR
Q558 HVTKTC3200GRT T.R KTC3200GR
Q559 HVTKTC3200GRT T.R KTC3200GR
Q560 HVTKTC3200GRT T.R KTC3200GR
Q561 HVTKTC3200GRT T.R KTC3200GR
Q562 HVTKTC3200GRT T.R KTC3200GR
Q563 HVTKTC3200GRT T.R KTC3200GR
Q564 HVTKTC3200GRT T.R KTC3200GR
Q565 HVTKTC3200GRT T.R KTC3200GR
Q601 HVTKTA1268GRT T.R KTA1268GR
Q602 HVTKTA1268GRT T.R KTA1268GR
Q603 HVTKTA1268GRT T.R KTA1268GR
Q604 HVTKTA1268GRT T.R KTA1268GR
Q605 HVTKTA1268GRT T.R KTA1268GR
Q681 HVTKSC2785YT T.R KSC2785Y
Q682 HVTKSC2785YT T.R KSC2785Y
Q683 HVTKSC2785YT T.R KSC2785Y
Q684 HVTKSC2785YT T.R KSC2785Y
Q685 HVTKSC2785YT T.R KSC2785Y
Q901 HVTKSC2785YT T.R KSC2785Y
Q938 HVTKRA107MT T.R KRA107M
Q939 HVTKRA107MT T.R KRA107M
Q941 HVTKSC2785YT T.R KSC2785Y
Q942 HVTKSC2785YT T.R KSC2785Y
Q943 HVTKSC2785YT T.R KSC2785Y
Q951 HVTKRC107MT T.R KRC107M
Q952 HVTKRA107MT T.R KRA107M
Q960 HVTKRC107MT T.R KRC107M
Q961 HVTKTA1024YT T.R A1024Y
Q991 HVTKRC107MT T.R KRC107M
harman/kardon
AVR 155/230 Service Manual
Page 15 of 92
