Harman Kardon AVR 155

MAIN PCB ASSY
Ref. # Part Number
Description
Value
R690 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R696 CRD25TJ470T RES , CARBON 47 OHM 1/5W J
R697 CRD25TJ470T RES , CARBON 47 OHM 1/5W J
R698 CRD25TJ470T RES , CARBON 47 OHM 1/5W J
R699 CRD25TJ470T RES , CARBON 47 OHM 1/5W J
R700 CRD25TJ470T RES , CARBON 47 OHM 1/5W J
R771 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R772 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R773 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R774 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R775 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R781 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R782 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R783 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R784 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R785 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R900 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R901 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R902 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R903 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R906 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R907 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R910 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R912 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R917 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R918 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R919 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R920 CRD25TJ393T RES , CARBON 39K OHM 1/5W J
R932 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R939 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R940 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R941 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R942 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R944 CRD25TJ223T RES , CARBON 22K OHM 1/4W J
R946 CRD25TJ223T RES , CARBON 22K OHM 1/4W J
R947 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R948 CRD25TJ153T RES , CARBON 15K OHM 1/4W J
R955 CRD20TJ203T RES , CARBON 20K OHM 1/5W J
R956 CRD20TJ394T RES , CARBON 390K OHM 1/5W J
R957 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R960 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R961 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R962 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R963 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R966 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R986 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R987 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R988 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R989 CRD20TJ302T RES , CARBON 3K OHM 1/5W J
R991 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J
R992 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R998 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
CMYAVR155 HEAT SINK ASS'Y ASS'Y
CHD1A012R SCREW , SPECIAL SCREW
CHD3A012R SCREW , SPECIAL SCREW
CMD1A398 BRACKET , PCB BRACKET
CMD1A417 BRACKET , PCB BRACKET
CMY1A249 HEAT SINK HEAT SINK
CMY2A249 HEAT SINK HEAT SINK
CMY3A269 HEAT SINK HEAT SINK
CTB3+10JR SCREW SCREW
CTB3+8JR SCREW SCREW
K8AYG6260 COMPOUND , SILICONE SILICONE
Q652 HVT2SB1560-OKM T.R , POWER TR
Q653 HVT2SB1560-OKM T.R , POWER TR
Q654 HVT2SB1560-OKM T.R , POWER TR
Q655 HVT2SB1560-OKM T.R , POWER TR
Q657 HVT2SD2390-OKM T.R , POWER TR
Q658 HVT2SD2390-OKM T.R , POWER TR
Q659 HVT2SD2390-OKM T.R , POWER TR
harman/kardon
AVR 155/230 Service Manual
Page 18 of 92
