Harman Kardon AVR 155

MAIN PCB ASSY
Ref. # Part Number
Description
Value
Q660 HVT2SD2390-OKM T.R , POWER TR
Q661 HVT2SB1560-OKM T.R , POWER TR
Q670 HVT2SD2390-OKM T.R , POWER TR
CTW3+8JR SCREW SCREW
CWE8202150AA WIRE ASS'Y WIRE
BN19 CWB3FE03250UP WIRE ASS'Y WIRE
BN20 CWB3FC04280UP WIRE ASS'Y WIRE
BN82 CWB1C902050EN WIRE ASS'Y WIRE
BN83 CWB1C902050EN WIRE ASS'Y WIRE
BN84 CWB1C902050EN WIRE ASS'Y WIRE
BN85 CWB1C902050EN WIRE ASS'Y WIRE
BN86 CWB1C902050EN WIRE ASS'Y WIRE
BN98 HJP08GA130ZK WAFER WAFER
BN99 CWB1C902250BM WIRE ASS'Y WIRE
CN11 CJP13GA117ZY WAFER , CARD CABLE WAFER
CN12 CJP21GA115ZY WAFER , CARD CABLE WAFER
CN61 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN62 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN63 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN64 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN65 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN90 CJP02GA89ZY WAFER WAFER
CN91 CJP02GA89ZY WAFER WAFER
CN92 CJP02KA060ZY WAFER WAFER
C563 CCEA1CH101T CAP , ELECT 100UF 16V
C631 CCEA1JH101E CAP , ELECT 100UF 63V
C632 CCEA1JH101E CAP , ELECT 100UF 63V
C633 CCEA1JH101E CAP , ELECT 100UF 63V
C634 CCEA1JH101E CAP , ELECT 100UF 63V
C635 CCEA1JH101E CAP , ELECT 100UF 63V
C636 CCEA1JH101E CAP , ELECT 100UF 63V
C637 CCEA1JH101E CAP , ELECT 100UF 63V
C638 CCEA1JH101E CAP , ELECT 100UF 63V
C639 CCEA1JH101E CAP , ELECT 100UF 63V
C640 CCEA1JH101E CAP , ELECT 100UF 63V
C902 CCET50VKL4682NK CAP , ELECT 6800UF/50V
C904 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
C906 CCEA1EH102E CAP , ELECT 1000UF 25V
C909 CCET50VKL4682NK CAP , ELECT 6800UF/50V
C915 CCET50VKL4682NK CAP , ELECT 6800UF/50V
C916 CCET50VKL4682NK CAP , ELECT 6800UF/50V
ET01 CMD1A387 BRACKET , PCB BRACKET
JK90 CJJ4M040Z JACK , BOARD (SW) JACK
JK91 CJJ5R006Z TERMINAL , SPEAKER TERMINAL
JK92 CJJ5P020Z TERMINAL , SPEAKER TERMINAL
JW90 CWE8212120VV WIRE , RED WIRE
JW91 CWE8212180VV WIRE ASS'Y WIRE
JW92 CWEE212080VV WIRE ASS'Y WIRE
JW93 CWEE202110VV WIRE (BLACK) WIRE
L501 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L502 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L503 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L504 CLEY0R5KAK COIL , SPEAKER 0.5UH K
L505 CLEY0R5KAK COIL , SPEAKER 0.5UH K
OL91 KJJ7A022Z OUTLET , AC(EUR/1P) A302D0061P
Q858 HVT2SA1360O T.R 2SA1360O
Q871 HVT2SA1360O T.R 2SA1360O
Q872 HVT2SA1360O T.R 2SA1360O
Q874 HVT2SA1360O T.R 2SA1360O
Q875 HVT2SA1360O T.R 2SA1360O
Q881 HVT2SC3423O T.R 2SC3423O
Q882 HVT2SC3423O T.R 2SC3423O
Q883 HVT2SC3423O T.R 2SC3423O
Q884 HVT2SC3423O T.R 2SC3423O
Q885 HVT2SC3423O T.R 2SC3423O
RY94 CSL1E002ZE RELAY , POWER G5PA-1 (DC 6V)
R656 CRF5EKR27HX2K RES , CEMENT 0.5UH K
R657 CRF5EKR27HX2K RES , CEMENT 0.5UH K
R658 CRF5EKR27HX2K RES , CEMENT 0.5UH K
R659 CRF5EKR27HX2K RES , CEMENT 0.5UH K
harman/kardon
AVR 155/230 Service Manual
Page 19 of 92
