Harman Kardon AVR 155

MAIN PCB ASSY
Ref. # Part Number
Description
Value
R660 CRF5EKR27HX2K RES , CEMENT 0.5UH K
R905 CRG1ANJ1R0H RES , METAL OXIDE FILM 1 OHM 1W J
R911 CRG1ANJ271H RES , METAL OXIDE(270/1W) 270 OHM 1W J
R990 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R993 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R995 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R997 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R999 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
TH91 KRTP42T7D330B THERMAL SENSOR , POSISTOR P42T7D330BW20
T902 CLT5I009ZE TRANS , SUB CD6002/N TRANS
POWER PCB ASSY
Ref. # Part Number
Description
Value
COP12027H AVR155/230 POWER PCB ASS'Y ASS'Y
C104 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C105 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C106 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C107 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C108 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C109 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C117 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C118 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C119 CCEA1JH470TS CAP , ELECT 47UF 63V
C120 CCEA1JH470TS CAP , ELECT 47UF 63V
C121 CCBS1E103ZFT CAP , CERAMIC(10000PF/25V) 0.01UF 25V
C131 CCEA1HH3R3T CAP , ELECT 3.3UF 50V
C750 CCEA1CH101T CAP , ELECT 100UF 16V
C751 CCEA1CH101T CAP , ELECT 100UF 16V
C852 CCEA1HH100T CAP , ELECT 10UF 50V
C853 CCEA1HH100T CAP , ELECT 10UF 50V
C854 CCEA1HH100T CAP , ELECT 10UF 50V
C855 CCEA1HH100T CAP , ELECT 10UF 50V
C856 CCEA1HH100T CAP , ELECT 10UF 50V
C902 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V
C903 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V
C906 CCEA1CH101T CAP , ELECT 100UF 16V
C907 CCEA1CH101T CAP , ELECT 100UF 16V
C912 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C919 CCKT1H102KB CAP , CERAMIC 1000PF 50V K
C920 CCEA1HH470T CAP , ELECT 47UF 50V
C921 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C922 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C923 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C924 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C925 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C926 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C927 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C928 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C931 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C932 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C933 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C934 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C935 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V
C936 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V
C937 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V
C938 CCEA1CH101T CAP , ELECT 100UF 16V
C939 CCEA1EH101T CAP , ELECT 100UF 25V
C940 CCEA1EH101T CAP , ELECT 100UF 25V
C953 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C954 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C957 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
D101 CVDZJ15BT DIODE , ZENER ZJ15B 1/2W
D102 HVDMTZJ27BT DIODE , ZENER MTZJ27B 1/2W
D104 CVD1N4003ST DIODE , RECT 1N4003
D105 CVD1N4003ST DIODE , RECT 1N4003
D108 CVD1N4003ST DIODE , RECT 1N4003
D109 CVDZJ8.2BT DIODE , ZENER ZJ8.2B 1/2W
D111 CVDZJ8.2BT DIODE , ZENER ZJ8.2B 1/2W
D114 CVD1N4003ST DIODE , RECT 1N4003
D115 CVD1N4003ST DIODE , RECT 1N4003
harman/kardon
AVR 155/230 Service Manual
Page 20 of 92
