Harman Kardon AVR 155

POWER PCB ASSY
Ref. # Part Number
Description
Value
D116 CVD1N4003ST DIODE , RECT 1N4003
D117 CVD1N4003ST DIODE , RECT 1N4003
D124 CVD1N4003ST DIODE , RECT 1N4003
D125 CVD1N4003ST DIODE , RECT 1N4003
D201 CVDZJ3.3BT DIODE , ZENER ZJ3.3B 1/2W
D801 CVD1SS133MT DIODE 1SS133
D802 CVD1SS133MT DIODE 1SS133
Q104 HVTKSC2316YT T.R KSC2316Y
Q911 HVTKTA1267YT T.R KTA1267Y
Q912 HVTKTC3198YT T.R KTC3198Y
Q913 HVTKTC3198YT T.R KTC3198Y
R101 CRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J
R108 CRD20TJ8R2T RES , CARBON 8.2 OHM 1/5W J
R109 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R110 CRD20TJ8R2T RES , CARBON 8.2 OHM 1/5W J
R112 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R113 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R120 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R121 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R122 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R750 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R751 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R875 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R876 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R877 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R878 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R879 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R883 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R884 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R885 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R886 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R887 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R891 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R893 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R894 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R895 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R896 CRD20TJ391T RES , CARBON 390 OHM 1/5W J
R901 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R913 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R917 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R918 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R919 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R920 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R921 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R922 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R923 CRD25TJ153T RES , CARBON 15K OHM 1/4W J
R924 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R925 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R926 CRD25TJ103T RES , CARBON 10K OHM 1/4W J
R927 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R928 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R941 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R942 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R956 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R957 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
VR82 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR83 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR84 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR85 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
VR86 CVN1RA221B02T RES , SEMI FIXED (220, B CURVE) KVSF637AVC
BN17 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) HEADER
BN20 CWB1C905120BM WIRE ASS'Y WIRE
BN43 CWB1C903200BM WIRE ASS'Y WIRE
BN96 CWB1C909180EN WIRE ASS'Y(9P, 2MM, 180MM) WIRE
BN97 CWB1C905120EN WIRE ASS'Y WIRE
CN13 CJP05GA01ZY WAFER(YMW025-05R) WAFER
CN19 CJP03GA90ZY WAFER WAFER
CN20 CJP04GA90ZM WAFER WAFER
CN32 CJP02GA19ZY WAFER , 2PIN WAFER
harman/kardon
AVR 155/230 Service Manual
Page 21 of 92
