Harman Kardon AVR 155

POWER PCB ASSY
Ref. # Part Number
Description
Value
CN33 CJP02GA19ZY WAFER , 2PIN WAFER
CN34 CJP02GA19ZY WAFER , 2PIN WAFER
CN35 CJP02GA19ZY WAFER , 2PIN WAFER
CN36 CJP02GA19ZY WAFER , 2PIN WAFER
CN47 CJP07GA117ZY WAFER WAFER
CN81 CJP07GA01ZY WAFER , STRAIGHT(7PIN) WAFER
CN89 CJP02GA01ZY WAFER , STRAIGHT, 2PIN WAFER
CN96 CJP09GA19ZY WAFER, STRAIGHT, 9PIN WAFER
CN97 CJP05GA19ZY WAFER , STRAIGHT WAFER
CN98 HJP08GB131ZK WAFER WAFER
C122 CCEA1JH101E CAP , ELECT 100UF 63V
C929 CCEA1VH222EZ CAP , ELECT (2200UF/35V, 12.5X31) 2200UF 35V
C930 CCEA1VH222EZ CAP , ELECT (2200UF/35V, 12.5X31) 2200UF 35V
C941 CCEA1EH682E CAP , ELECT(KR3, 25V/6800, 18X35.5) 6800UF 24V
D991 CVDKBU804FMA BRIDGE DIODE ASS'Y ASS'Y
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK
CTB3+12JR SCREW SCREW
HVDKBU804F DIODE , BRIDGE DIODE
K8AYG6260 COMPOUND , SILICONE SILICONE
D992 CVDKBU804FMA BRIDGE DIODE ASS'Y ASS'Y
CMY1A219 HEAT SINK (BRIDGE DIODE) HEAT SINK
CTB3+12JR SCREW SCREW
HVDKBU804F DIODE , BRIDGE DIODE
K8AYG6260 COMPOUND , SILICONE SILICONE
IC81 CVIST232CDR IC , RS232C(SO-16TYPE) ST(ST232CDR)
IC89 HVIKIA278R05PI REGULATOR (5V OUTPUT LOW DROP) KEC(KIA278R05PI)
IC90 CVIKIA278R15PI I.C , REGULATOR(15V OUTPUT LOW DROP) KEC(KIA278R15PI)
IC91 CVIKIA7915PI I.C , REGULATOR(15V, TO-220AB) KEC(KIA7915PI)
IC93 CVIKIA7905PI I.C , REGULATOR(-5V) KEC(KIA7815PI)
IC94 HVIKIA7809API I.C , REGULATOR +9V KEC(KIA7909API)
JK75 HJSTORX177L MODULE , OPTICAL(RX) TORX177L
JK76 HJSTORX177L MODULE , OPTICAL(RX) TORX177L
JK97 CJJ9W001Z JACK , 9P D-SUB FEMALE(RS-232C, SEMCO) JACK
Q852 HVTKTD600KGR T.R , BIAS KTD600KGR
Q853 HVTKTD600KGR T.R , BIAS KTD600KGR
Q854 HVTKTD600KGR T.R , BIAS KTD600KGR
Q855 HVTKTD600KGR T.R , BIAS KTD600KGR
Q856 HVTKTD600KGR T.R , BIAS KTD600KGR
R104 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J
R105 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J
R106 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J
R107 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J
SW95 CST1A010Z SW , TACT TACT SWITCH
SW98 HSH2B018Z SW , PUSH SPUJ19XSM011
INPUT PCB ASSY
Ref. # Part Number
Description
Value
COP12028H AVR155/230 INPUT PCB ASS'Y ASS'Y
C201 CCUS1H221JA CAP , CHIP 220PF 50V J
C202 CCUS1H221JA CAP , CHIP 220PF 50V J
C203 CCUS1H221JA CAP , CHIP 220PF 50V J
C204 CCUS1H221JA CAP , CHIP 220PF 50V J
C205 CCUS1H221JA CAP , CHIP 220PF 50V J
C206 CCUS1H221JA CAP , CHIP 220PF 50V J
C209 CCUS1H221JA CAP , CHIP 220PF 50V J
C210 CCUS1H221JA CAP , CHIP 220PF 50V J
C211 CCUS1H221JA CAP , CHIP 220PF 50V J
C212 CCUS1H221JA CAP , CHIP 220PF 50V J
C213 CCUS1H221JA CAP , CHIP 220PF 50V J
C214 CCUS1H221JA CAP , CHIP 220PF 50V J
C215 CCUS1H221JA CAP , CHIP 220PF 50V J
C216 CCUS1H221JA CAP , CHIP 220PF 50V J
C219 CCUS1H221JA CAP , CHIP 220PF 50V J
C220 CCUS1H221JA CAP , CHIP 220PF 50V J
C221 CCUS1H221JA CAP , CHIP 220PF 50V J
C222 CCUS1H221JA CAP , CHIP 220PF 50V J
C223 CCUS1H221JA CAP , CHIP 220PF 50V J
C224 CCUS1H221JA CAP , CHIP 220PF 50V J
C260 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C269 CCUS1A105KC CAP , CHIP 1UF 10V K
harman/kardon
AVR 155/230 Service Manual
Page 22 of 92
