Table A2 – Speaker/Channel Setting Defaults
Default Settings
Your Settings
Position 1
Your Settings
Position 2
Front Left/Right Speakers ON
Center Speaker ON
Surround Left/Right Speakers ON
Surround Back Left/Right Speakers
(AVR 1710/AVR 171 only)
OFF
Subwoofer ON
Front Left/Right Speakers Crossover Frequency 100Hz
Center Speaker Crossover Frequency 100Hz
Surround Left/Right Speakers Crossover Frequency 100Hz
Surround Back Left/Right or Left/Right Front Height Speakers
Crossover Frequency (AVR 1710/AVR 171 only)
100Hz
Subwoofer Mode (if Front Speakers are set to Large) L/R + LFE
Front Left Level 0dB
Center Level 0dB
Front Right Level 0dB
Surround Right Level 0dB
Surround Back Right/Front Height Right Level
(AVR 1710/AVR 171 only)
0dB
Surround Back Left/Front Height Left Level
(AVR 1710/AVR 171 only)
0dB
Surround Left Level 0dB
Subwoofer Level 0dB
Table A3 – Delay Setting Defaults
Speaker Position
Distance From Speaker
to Listening Position
Your Delay Settings
Position 1
Your Delay Settings
Position 2
Front Left 10 feet (3 meters)
Center 10 feet (3 meters)
Front Right 10 feet (3 meters)
Surround Right 10 feet (3 meters)
Surround Left 10 feet (3 meters)
Surround Back Right/Front Height Right 10 feet (3 meters)
Surround Back Left/Front Height Left 10 feet (3 meters)
Subwoofer 10 feet (3 meters)

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
