Harman Kardon AVR 1610 User Manual

43
ENGLISH
AVR
Appendix
Surround Mode Description Incoming Bitstream or Signal
DTS Neo:6
Mode Group
DTS Neo:6 analog processing is available with DTS and DTS 96/24 signals and
two-channel analog or PCM signals to create a 3-, 5- or 6-channel presentation.
See below
DTS Neo:6
Cinema
Depending on the number of speakers in your system, select 3-, 5- or 6-channel
modes, enhanced for movie or video presentations.
•DTS2/2/.0or.1,3/2/.0or.1
•DTS96/24
•Analog(two-channel)
•PCM(32kHz,44.1kHzor48kHz)
DTS Neo:6
Music
Available only in 5- and 6-channel modes, creates a surround presentation
suitable for music recordings.
•DTS2/2/.0or.1,3/2/.0or.1
•DTS96/24
•Analog(two-channel)
•PCM(32kHz,44.1kHzor48kHz)
HARMAN NSP A HARMAN proprietary technology, NSP uses sophisticated digital processing to deliver
a true natural sounding three-dimensional listening experience from conventional
2-channel stereo sources like CDs and stereo broadcasts. While preserving the
recording’s original timbre and spatial balance, HARMAN NSP creates a simulated
listening space that automatically adjusts to suit the type of program you are
listening to. Adjustments are available for the size of the simulated space and for
how aggressively NSP automatically adjusts the simulated space to compliment the
program material.
•Analog(two-channel)
•Tuner
•PCM(32kHz,44.1kHz,48kHz,96kHz)
5-Channel Stereo Useful for parties, the left- and right-channel information is played through both
the front and surround speakers on each side, while the center speaker plays a
summed mono mix.
•Analog(two-channel)
•Tuner
•PCM(32kHz,44.1kHz,48kHz,96kHz)
7-Channel Stereo
(AVR 1710/
AVR 171 only)
Expands the 5-Channel Stereo presentation to include the surround back channels. •Analog(two-channel)
•Tuner
•PCM(32kHz,44.1kHz,48kHz,96kHz)
2-Channel Stereo Turns off all surround processing and plays a pure two-channel signal or a downmix
of a multichannel signal. The signal is digitized and bass management settings are
applied, making it appropriate when a subwoofer is used.
•Analog(two-channel;DSPdownmixavailableformultichannel)
•Tuner
•PCM(32kHz,44.1kHz,48kHz,96kHz)
Table A10 – Surround Modes – continued

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
