Table A11 – Remote Control Function List
Radio
NETWORK/vTUNER
Media Server
DMC1000
No. Button Name AVR
FM AM
Blu-ray/DVD TV USB/iPod
01
AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On
02 AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off
03* Zone 2 Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle Zone 2 Toggle
04 Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute
05 Cable/Sat Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
06 STB Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
07 TV Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
08 Disc Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
09 MHL Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
10 Aux Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
11
Audio Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
12 Game Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
13 AVR Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
14 USB Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
15 Network Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
16 Radio Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel
17 Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes
18 OSD/Menu Menu Start Menu Menu Menu Menu Menu
19 Up Up Up Up Up Up Up Up
20 Left Left Left Left Left Left Left Left
21 OK OK Select Enter Setup Select Enter Setup
22 Right Right Right Right Right Right Right Right
23 Down Down Down Down Down Down
Down Down
24 Back/Exit Bypass Clear Exit/Cancel Exit Exit Cancel Exit
25 Home MHL Home
26 1 1 1 1 1 1 1 1 1
27 2 2 2 2 2 2 2 2 2
28 3 3 3 3 3 3 3 3 3
29 4 4 4 4 4 4 4 4 4
30 5 5 5 5 5 5 5 5 5
31 6 6 6 6 6 6 6 6 6
32 7 7 7 7 7 7 7 7 7
33 8 8 8 8 8 8 8 8 8
34 Clear Clear Clear Exit Clear Clear
35 9 9 9 9 9 9 9 9 9
36 0 0 0 0 0 0 0 0 0
37 Test
38 Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume +
39 Delay
40 Sleep Sleep Sleep Sleep Sleep Sleep Sleep Sleep Sleep
41 Channel/Tuner Up Channel Up Scan Up Channel Up Page Up Channel Up (+10) Channel Up Page Up
42 Volume - Volume – Volume – Volume – Volume – Volume – Volume – Volume – Volume –
43
Info/Option Options Options Options Options Options
44 Dim
45
Channel/Tuner
Down
Channel Down Scan Down Channel Down Page Down Channel Down Disc Skip Channel Down Page Down
46 Preset Scan
47 Direct
48 Memory FAV Repeat/Live TV
49 RDS
50 Previous Slow Down Back Previous Thumb Down Skip Down Scan Down Previous
51 Rew

Previous Rew

Rew

Rew

R. Search Rew

Rew

52 FF

FF

Next FF

FF

FF

F. Search FF

FF

53 Next Slow Up Replay Next Thumb Up Skip Up Scan Up Next
54 Top Menu
55 Stop Stop Stop Stop Stop Stop Stop Stop
56 Play

/Pause Play

/Pause Play

/Pause Play

/Pause Play

/Pause Play

/Pause Play

/Pause Play

/Pause
57 Prev. CH Prev. Ch
* AVR 1710/AVR 171 only.

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
