FUNCTION LIST 41
Function List
No. Button Name Tape VCR (VID 1) TV (VID 2) CBL (VID 3) SAT(VID 3)
1 Power On Power On Power On Power On Power On Power On
2 Power Off Power Off Power Off Power Off Power Off Power Off
3 Mute Mute
4 AVR
5 DVD
6 CD
7 Tape Tape Select
8 VID 1 VCR Select
9 VID 2 TV Select
10 VID 3 VID 3 Select
11 VID 4
12 AM/FM
13 6 Ch. Select
14 SPL
15 Sleep Channel + Channel + Channel + Channel +
16 Test
17 TV TV/VCR TV/VCR TV/Cable TV/Sat
18 Volume Up Volume Up Volume Up
19 Surround Select Channel – Channel – Channel –
20 Night
21 Spare
22 Volume Down Volume Down
23 Channel/Guide Info/Guide Info/Guide
24 ⁄ Up Up Up Up
25 Speaker/Menu Menu Menu Menu Menu
26 fi Left Left Left Left
27 Set Enter Enter Enter Enter
28 fl Right Right Right Right
29 Digital/Exit Exit Exit Exit Exit
30 ¤ Down Down Down Down
31 Delay/Prev. Ch. Prev Channel Prev Channel Prev Channel
32 1 1111
33 2 2222
34 3 3333
35 4 4444
36 5 5555
37 6 6666
38 7 7777
39 8 8888
40 Tun-M
41 9 9999
42 0 0000
43 Memory
44 Tune Up
45 Direct
46 Clear Clear Clear Clear Clear
47 Preset Up
48 Tune Down
49 OSD OSD OSD OSD OSD
50 RDS
51 Preset Down
52 M1 Cancel Sleep PPV Cancel
53 M2 Fav Fav
54 M3 Bypass Next
55 M4 Music Alt
56 Rewind Rewind Rewind Day – Day –
57 Play Play Play
58 Fast Forward Fast Fwd Fast Fwd Day + Day +
59 Record Record/Rec.Pause Record
60 Stop Stop Stop
61 Pause Pause
62 Skip Down Scan – Page – Page –
63 Skip Up Scan + Page + Page +

Harman Kardon AVR 3500 Specifications

Power

continuous average power (stereo mode)	55 watts per channel into 8 ohms
continuous average power (five-channel surround mode)	45 watts per channel into 8 ohms
high instantaneous current capability (HCC)	±28 amps

Tuner Specifications

usable sensitivity	IHF 1.3µV/13.2dBf
THD at 1kHz with 100% modulation (mono)	0.2%
THD at 1kHz with 100% modulation (stereo)	0.3%

Weight and Dimensions

dimensions (H x W x D)	165mm x 440mm x 435mm
weight	14kg
