Harman Kardon AVR 3550

■ ELECTRICAL PARTS LIST
REF NO. PART NO. DESCRIPTION REMARKS
CUP11516X PCB , FRONT
▶CAPACITOR
C701,702 HCBS1H390JT CAP , CERAMIC 39PF 50V J
C703 HCBS1H821KBT CAP , CERAMIC 820PF 50V K
C704,735,773,774
777 778 864
C705,711 HCBS1H102KBT CAP , CERAMIC 1000PF 50V B
C706 HCBS1H561KBT CAP , CERAMIC 560PF 50V K
C707,783,784 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C708,713,730,732
736 770 771 805
806,859~862
C709,810,811 HCEA1CH101T CAP , ELECT 100UF 16V
C710 HCEA1HH2R2T CAP , ELECT 2.2UF 50V
C712 HCEA1HH1R0T CAP , ELECT 1UF 50V
C714,775,776 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C715,813,814 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C716,872,873 HCEA1CH331T CAP , ELECT 330UF 16V
C719~721 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C722 HCBS1H220JT CAP , CERAMIC 22PF 50V J
C723 CCFT1H104ZF CAP , SEMI 0.1UF 50V ZF
C725,729,865 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C726,863,886 HCEA0JH102T CAP , ELECT 1000UF 6.3V
C731 HCEA1HH100T CAP , ELECT 10UF 50V
C733 HCEA1EH470T CAP , ELECT 47UF 25V
C737,738 HCBS1H180JT CAP , CERAMIC 18PF 50V J
C779,780,791,792
868 869
C781,782,787~790
866 867
C785,786 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C793,794,799,800 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C795,796 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C797,798 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C850,851 HCBS1H471KBT CAP , CERAMIC 470PF 50V K
C852,874,882,883 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C870,871 HCBS1H681KBT CAP , CERAMIC 680PF 50V K
C875~878 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C880 HCEA1AH221T CAP , ELECT 220UF 10V
C734,885 BCES0HD104 CAP , GOLD JP EECS0HD104V
C853 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
▶DIODE
D701~703,705~716
718~721,729~754
756~759
D725~727,761,
777 779
1SS133T-77
CVD30BSGATAAT L.E.D , GREEN (TAPPING)
HVD1SS133MT DIODE
HCEA1CKS470T CAP, ELECT 47UF 16V
HCEA1CKS100T CAP , ELECT 10UF 16V
HCEA1VH100T CAP , ELECT 10UF 35V
HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
