Harman Kardon AVR 435 Service Manual

harman/kardon AVR435/230 Bill of material
DSP BD
Part Number
Description
Posistion No
H03-IC74HC4094D-1 IC CD74HC4094D(R-PDSO-G16) SOP16 IC502
H03-ICM24C04WD2-7 IC-EEPROM M24C04WMN6T IC503
H03-IC74VC244G5-1 IC-LOGIC 74VHC244M M20B INVERTER CMOS IC504
H03-IC74LV1G125-9 IC SN74LVC1G125DVB SOT23 IC505 506 607
H03-ICKA78R08I2-A IC-KIA78R08API TO-220IS-4PIN IC507
H03-ICCS42518E6-8 IC LOGIC CS42518CQ QFP64 IC606
H03-IC74LV1G125-9 IC SN74LVC1G125DVB SOT23 IC608
H03-ICSN74HCU04-6 IC SN74HCU04D IC704 705
H03-ICPC17T10B1-8 IC PHOTOCOUPLER PC-17T1 DIP4 KODENSHI IC851
H03-ICTMS320DA6-0 IC FLOATING-POINT DSP TMS320D610A PQFP208 IC901
H03-ICAT49BV162-8 IC FLASH MEMORY AT49BV162AT-70TI 48T IC902
H03-ICK4S1616M6-4 IC-SDRAM K4S161622H-TC60 OR TC80 IC903
H03-ICM317TO252-1 IC 3-TERMINAL POS VOL REG NJM317DL1 TO-252 IC904
RS3AD0000NA-0 RES CHIP 0 OHM +0% 62MI5W 0603 JUM1 2 R601
H03-LAINB047ACR-9 LF 4U7H +10% 1.7 OHM 190.0A L501
H03-FB2K52012NN-0 FBEAD SURFACE MT 2500OHM FCM2012H-252T02 L504 604 610 700 901 904 905
H03-FB3012012CN-8 FBEAD SURFACE MT FCM2012C-301T04 0805 L508
H03-FB3012012CN-8 FBEAD SURFACE MT FCM2012C-301T04 0805 L601 602 605 606 607
H03-LAINB0470CR-8 LF 47U0H +10% 5.8 OHM 500MI0A L702 703 704 705
RS3BB0000NA-5 RES CHIP 0 OHM +5% 100MI0W 0805 L706
H03-FB2K52012NN-0 FBEAD SURFACE MT 2500OHM FCM2012H-252T02 L903
H03-WN19SB00000-1 CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0 N407 801
H03-WG09SB81000-3 WIRECONASY DL 2.0MM 09P 100MM UL1007 RIBBON 26 1 N501
H03-WN27AI00000-A CONNECT 1.25mm 27P GF120-27S-LS N502
H03-WN11SB00000-3 CONN 2.0MM 11P MA ST NAT MOLEX 35336-1110 0 0 N503
H03-WN06AB00001-A CNT PLUG BD'BD SOCKET 2.0mm 35237-0610 6P N504
H03-WN09SB00000-5 CONNECT 2.0mm 9P GIL-S-9P-S2T2-EF N506
H03-WN05SB00000-6 CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF N701
H03-WN19AB00000-4 CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0 N802
H03-WG06SB82800-7 WIRE ASS'Y UL1007#26 STR 280MM 2.0MM 6P WHT N803
H03-WG01S022018-5 WIRE ASS'Y UL1007#18 220MM 1P BLK TERMINAL N805
H03-SOTOR179LBA-6 D-LEM TORX-179L NJ701 702 703
H03-SOTOT179LBA-2 D-LEM TOTX-179L NJ704
H03-SOJB04013HN-0 JACK RCA 4P OR ,OR, OR, OR JB040131HN NJ705
H03-SORA40RSCNN-5 JACK RCA 4P JB040131QN WH BU RD GY NJ801
H03-SORA40RSANN-1 JACK RCA 4P JB040131ZN GN BN PP TA NJ802
H03-TRDTC114YNI-0 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q501 502 503 504 505 506 507 508 509 510
602
H03-TRMPSA06NNA-A TR-SLPLF MPSA06 N 500MI0A TO-92 Q511
H03-TRDTC114YNI-0 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q601
H03-TRKTA107MNA-2 TR-SLPSWA KRA107M P Q851
RS3AD0151NA-1 RES CHIP 150R0 OHM +5% 62MI5W 0603 R132 251 252 253 256
RS3AD0103NA-1 RES CHIP 10K0 OHM +5% 62MI5W 0603
R254 255 259 260 501 502 519 520 533 551
552 559 969
RS3AD0103NA-1 RES CHIP 10K0 OHM +5% 62MI5W 0603 R257 258 523 535 536 561 923
RS3AD0203NA-8 RES CHIP 20K0 OHM +5% 62MI5W 0603 R261 264
RS3AD0432NA-4 RES CHIP 4K3 OHM +5% 62MI5W 0603
R262 400 401 402 403 411 412 444 452 459
460 474 475 476 477 478 479
RS3AD0512NA-6 RES CHIP 5K1 OHM +5% 62MI5W 0603 R263
RS3AD0104NA-A RES CHIP 100K0 OHM +5% 62MI5W 0603
R265 266 414 415 448 449 480 491 492 499
556 702 706 724 730
RS3AD0101NA-5 RES CHIP 100R0 OHM +5% 62MI5W 0603 R267 268 630 632 645 981 984 985 986
RS3AD0122NA-8 RES CHIP 1K2 OHM +5% 62MI5W 0603
R405 416 417 418 419 425 426 429 430 431
445 446 483 484 485 486 609 612
RS3AD0562NA-2 RES CHIP 5K6 OHM +5% 62MI5W 0603
R406 427 428 432 433 434 435 438 443 450
453 458 481 482 487 488
RS3AD0561NA-4 RES CHIP 560R0 OHM +5% 62MI5W 0603
R439 440 447 454 456 457 489 490 703 704
709 726 743
