harman/kardon AVR435/230 Bill of material
SURROUND BD
Part Number
Description
Posistion No
RM3FC0100BN-7 RMOF 10R0 OHM +5% 1.0W R245 345 545
RC3DI0104IN-5 RCF 100K0 OHM +5% 250MI0W R246 346 546
RT6BA0201NB-A PR 200R0 OHM +30% 100MI0W VR201
H03-RT7EA0201NB-1 PR 200R0 OHM +20% 500MI0W VR301 501
H03-WC1201005C1-4 WIRE ASS'Y UL1007 #20 TS 100MM 1P BLK
DSP BD
Part Number
Description
Posistion No
3SA-4211EU-DGMI-1-A IMA DSP BD AVR435EU
CSEIE068ABB-4 CAP,CHIP FORM,6P8 +-0.5P,50V 0603,C0G C1
CZKII0102BC-7 CAP CHIP 1N0F +10% -10% 50.0V X7R 0603 C251 252 646
CZJII0101BE-2 CAP CHIP 100P0F +5% -5% 50.0V NP0 0603 C253 254 255 256 510 542 543
CZZFI0104BF-8 CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C257 263 292 503 507 513 516 517 518 522
528 614 615 622 624 628 630 632 634 705
708 710 714 721 817 818 903 910 913 922
925 926 927 930 945 947 961 980 981 982
984 985 986 988 989 990 991 929 946 960
987
CEMFC01072E-8 CE 100UF 16V +/-20% 5X11 P2.5MM ELIET C258 259 265 267 527 744 745
CZZFI0104BF-8 CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C260 261 413 414 447 448 449 455 490 493
509 526 723 742 901 918 919 920 921 928
948 949 950 951 952 953 954 955 956 957
962 963 964 965 966 967 968 969 970 971
972 973 974 975 976 977 978 983 992 620
CEHFC01072S-9 CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C C264 508 515 623 821 822 904 912
CEHFC01062S-0 CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C400 401 402 403 421 422 423 424 425 426
427 428 436 440 441 451 453 456 457 459
461 462 496 497 519 520 521 530 629 631
633 635 902
CCKIC0471NC-9 CAP CERAMIC 470PF 50V K X7R TAP C411 431 432 433
CCKIC0561NC-8 CAP CERAMIC 560PF 50V K X7R TAP
C412 415 434 435 454 458 475 476 487 488
489 495
CCKIC0272NC-4 CAPACITOR CERAMIC 2N7F 50V K X7R TAP
C416 417 418 419 429 430 438 439 450 460
470 471 481 482 483 484
CZJII0470BE-4 CAP CHIP 47P0F +5% -5% 50.0V NPO 0603 C443 491 541 544
CZJII0470BE-4 CAP CHIP 47P0F +5% -5% 50.0V NPO 0603 C444 492
CZJII0101BE-2 CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C501 502 504 505 506 801 802 803 804 805
806 807 808 809 810 811 812 813 814 815
816
CEHFC04762S-0 CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C C514
CEHIC01042S-5 CE 100NF +20% 50V SSE TYPE D4XL7 P2.5MM 85C C525
H03-CEZXA0479MN-0 CM 47MI0F +80%-20% 5.5V 70C SCDA5R5473V C557
CEHEC0477MN-A CE 470U0F +20% 10.0V 6.3X11 85C ELITE P5MM C601 959
CZKII0223CC-5 CAP CHIP 22NF 50V B K X7R 0805 C602
CZKII0103BC-5 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 C603 604 647 648 701 703 706 717
CZZII0104CF-8 CAP CHIP 100N0F +80% -20% 50.0V Y5V 0805 C619
CZJII0102CC-3 CAP CHIP 1nF 50V X7R J 0805 C621
CEHIC01055E-6 CE 1UF +20% 50V D5XL11 P5MM 85C C625
CZZII0104CF-8 CAP CHIP 100N0F +80% -20% 50.0V Y5V 0805 C627
CZKII0103BC-5 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 C645
CZJII0220BE-5 CCCFMIC 22P0F +5% -5% 50.0V NP0 0603 C700 702 720 743
CEHDC0108NN-3 CE 1MI0F +20% 6.3V 8X11.5 85C ELITE P5MM C823 824 825
CEHIC04755E-6 CE 4U7F +20% 50.0V 85C P5MM C958
H03-DS1S50094NB-5 D-SLP 1SS355 35.0V 225MI0A D501 502 506 508
H03-DS1S50094NB-5 D-SLP 1SS355 35.0V 225MI0A D503 504 505 507 851
H03-FYACF333TNN-A FILTER ACF451832-333-T E901
H03-ICLM02068D2-5 IC-OPERAMP NJM2068M-TE1 DUAL SOP8 IC251 252 401 402 404 406
H03-ICD703033E1-0 IC-MICOM FLASH NEC UPD70F3033BGF 0228KK001 JAPAN QFP100 IC501
