Harman Kardon AVR 435 Service Manual

harman/kardon AVR435/230 Bill of material
SURROUND BD
Part Number
Description
Posistion No
CCKID0271NN-0 CC 270P0F +10% -10% 50.0V 2B4 C206 306 506
CCJIC0120NN-2 CAP CERAMIC 12PF 50V J CH TAP C207 307 507
CEHEC02275E-9 CE 220UF +20% 10.0V D6.3XL11 P5MM 85C C208 308 508
CCJIC0330NE-9 CAP CERAMIC 33PF 50V +-5% NPO C209 309 509
CPJJC0683NN-A CAP POLY NON METAL 68NF 63V J TAP C210 310 510
H03-CEMKC0106AH-9 CAP ELEC 10UF 100V M 6.3X11 SHL C211 311 511
H03-CPKJC0104NN-2 CAP POLY NON METAL 0.1UF 63V K TAP PCMT365 75104 C213 214 313 314 513 514
CCKIC0332NA-5 CC 3N3F +10% -10% 50.0V Y5P C215 315 517
CCKIC0472NA-0 CC 4N7F +10% -10% 50.0V Y5P C216 316 516
CPIKC0473NN-0 CPF 47N0F +10% 100.0V C601 602 603
CEMFA02285E-5 CE 2200UF 16V M 12.5X20 P5MM C604
CEMFA0828BK-0 CAP ELEC 8200UF 16V M 18X25 P7.5MM ELITE C605
CEMFA0688BK-1 CAP ELEC 6800UF 16V M 16X25 85C 120HZ ELITE C606
H03-DG1N04148NB-A D-SLP 1N4148 100.0V 150E-3A
D101 201 202 203 204 301 302 303 304 501
502 503 504
H03-DRBU604F0NA-4 DIODE BRIDGE BU6-04F FRONTIER D601
H03-FURN23A1563-5 FUSE 663 SERIES 3.15 250V 3.15A LT-5 TIMELUG F601 602
H03-ZNMSA4004SN-A TERMLUG GND G101 102 103 105
H03-LCNNNA050NA-7 LFA 1MM 10MM 5 LEFT 0.0MM NONE L201 301 501
H03-WS6262605EN-1 WIRECONASY DL 2.0MM 6P 260MM UL1533 SHIELD 26 1 N401
H03-WN10SB00000-6 CONNECT 2.0MM 10P GIL-S-10P-S2T2-EF N402
H03-WN03SD100WH-1 CONN WAFER 2.5MM 3P 5267-03A WHT N403
H03-WG06SE81200-2 WIRE ASS'Y UL1007#16 120mm 3.96mm 6P RED N404
H03-SOPA8SH0612-5 JACK SPEAKER 8P SH0612707P NJ401
H03-WN02AD00000-5 CONNECT WAFER 2.5mm 2P 5268-02A WHT ANGLE P201 301 501
H03-WH800012P36-6 PIN HEADER YFW-800-01 2.36PI P405
H03-RP3NA0101HJ-4 THERMISTOR ASS'Y RP3NA-0101-NZ PO10
H03-RP3NA0101NN-5 POS 100R0 OHM 16.0V PO11
H03-TRKTA1268NA-A TR-SHPLF KTA1268BL P 100MI0A 120V Q101 206 306 506
H03-TRKTC3200NA-4 TR-SHPLF KTC3200BL N 100MI0A 120V
Q201 202 203 207 220 301 302 303 307 320
501 502 503 507 520
H03-TRKTC3198NA-9 TR-SLPLF KTC3198BL N 150MI0A Q204 304 504
H03-TR2SA1145NA-8 TR-SLPLF 2SA1145Y TO-92MOD P -50MI0A -150V Q205 305 505
H03-TRKTA1360BE-5 TRANSISTOR PNP KTA1360 TO-126 Q211 311 511
H03-TRKTC3423BE-A TRANSISTOR NPN KTC3423 TO-126 Q212 312 512
H03-TRKTC3114NE-9 TRANSISTOR NPN KTC3114 TO-126 Q214 314 514
H03-TR2SD2560B0-2 TRANSISTOR NPN 2SD2560 MT-100 Q218 318 518
H03-TR2SB1647B0-6 TRANSISTOR PNP 2SB1647 MT-100 Q219 319 519
RC3DI0103IN-7 RCF 10K0 OHM +5% 250MI0W R101
RC3DI0393IN-5 RCF 39K0 OHM +5% 250MI0W R102 242 342 542
RC3DI0331IN-5 RCF 330R0 OHM +5% 250MI0W R201 301 501
RM1DI0333IN-4 RMF 33K0 OHM +1% 250MI0W R202 212 302 312 502 512
RC3DI0100IN-2 RCF 10R0 OHM +5% 250MI0W R203 243 303 343 503 543
RC3DI0433IN-8 RCF 43K0 OHM +5% 250MI0W R204 304 504
RC3DI0271IN-8 RCF 270R0 OHM +5% 250MI0W R205 305 505
RC3DI0221IN-1 RCF 220R0 OHM +5% 250MI0W R206 207 306 307 506 507
RC3DI0471IN-0 RCF 470R0 OHM +5% 250MI0W R208 308 508
RC3DI0152IN-5 RCF 1K5 OHM +5% 250MI0W
R209 210 239 241 309 310 339 341 509 510
539 541
RC3DI0561IN-A RCF 560R0 OHM +5% 250MI0W
R211 214 215 216 217 218 311 314 315 316
317 318 511 514 515 516 517 518
RM1DI1651IN-7 RMF 1K65 OHM +-1% 250MI0W R213 313 513
RC3DI0223IN-8 RCF 22K0 OHM +5% 250MI0W R220 221 244 320 321 344 520 521 544
RC3DI0750IN-7 RES FILM 75 OHM 1/4W 5% R223 224 323 324 523 524
H03-RM3EG0180LN-2 RMOF 18R0 OHM +5% 500MI0W R225 233 325 333 525 533
RC3DI033AIN-6 RCF 3R3 OHM +5% 250MI0W R228 235 328 335 528 535
RC3DI0282IN-3 RCF 2K8 OHM +5% 250MI0W R229 329 529
RC3DI0821IN-A RCF 820R0 OHM +5% 250MI0W R230 330 530
H03-RI3IC022BEN-3 RW 220MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C R238 338 538
RC3DI0153IN-3 RCF 15K0 OHM +5% 250MI0W R240 340 540
Hanrman Consumer Group International
