Harman Kardon AVR 435 Service Manual

harman/kardon AVR435/230 Bill of material
MAIN BD
Part Number
Description
Posistion No
RC3DI0152IN-5 RCF 1K5 OHM +5% 250MI0W
R311 312 313 314 380 381 386 387 405 406
407 408 481 483 488 490
RC3DI0221IN-1 RCF 220R0 OHM +5% 250MI0W R317 318 319 320 409 410 411 412
RC3DI0271IN-8 RCF 270R0 OHM +5% 250MI0W R321 322 413 414 497
RC3DI0561IN-A RCF 560R0 OHM +5% 250MI0W
R323 324 325 326 329 330 333 334 335 336
337 338 421 422 423 424 425 426 427 428
429 430 431 432
RM1DI0333IN-4 RMF 33K0 OHM +1% 250MI0W R327 328 417 418
RM1DI1651IN-7 RMF 1K65 OHM +-1% 250MI0W R331 332 419 420
RC3DI0223IN-8 RCF 22K0 OHM +5% 250MI0W
R341 342 343 344 390 391 437 438 439 440
486 492
RC3DI0750IN-7 RES FILM 75 OHM 1/4W 5% R347 348 349 350 441 442 443 444
H03-RM3EG0180LN-2 RMOF 18R0 OHM +5% 500MI0W R351 352 367 368 445 446 447 448
RC3DI033AIN-6 RCF 3R3 OHM +5% 250MI0W R363 364 365 366 461 462 463 464
H03-RI3IC022BEN-3 RW 220MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C R378 379 471 472
RC3DI0393IN-5 RCF 39K0 OHM +5% 250MI0W R382 383 484 487 491 493 501 502
RC3DI0153IN-3 RCF 15K0 OHM +5% 250MI0W R384 385 482 489 503
RM3FC0100BN-7 RMOF 10R0 OHM +5% 1.0W R392 393 475 476
RC3DI0103IN-7 RCF 10K0 OHM +5% 250MI0W R485 516 605 606 608 610 611 613
RC3DI0822IN-8 RCF 8K2 OHM +5% 250MI0W R494
H03-RM3GC033ACN-2 RESISTOR METAL OXIDE 3R3 OHM +5% 2.0W R504 507 510
H03-RM3GC0100CN-2 RESISTOR METAL OXIDE 10R0 OHM +5% 2.0W R505
H03-RM3GC022ACN-3 RESISTOR METAL OXIDE 2R2 OHM +5% 2.0W R514
RC3DI0123IN-1 RCF 12K0 OHM +5% 250MI0W R607 612
RC3DI022AIN-2 RCF 2R2 OHM +5% 250MI0W R616
H03-WC1180175H1-1 WIRE ASS'Y 1P 175MM UL1015#18(TD) BLK W301
H03-WG116S500BK-0 WIRE ASS'Y UL1007#16 500MM 1P BLK TERMINAL W311
H03-WC1180905H1-0 WIRE ASS'Y WCL 1P 90MM UL1015#18(TD) BLK HOOK-UP 090-05-05 W401-2
RC3EA0682NN-1 RES. CARBON, 6.8K, 1/2W, +/-5%
BIAS
Part Number
Description
Posistion No
3SA-4120US-MAMI-1-3 FRONT L - BIAS BD AVR435US
3SA-4120US-MAMI-1-3 FRONT R - BIAS BD AVR435US
3SA-4120US-MAMI-1-3 SURROUND L - BIAS BD AVR435US
3SA-4120US-MAMI-1-3 SURROUND - R BIAS BD AVR435US
H03-RP3NA0101NN-5 POS 100R0 OHM 16.0V PO71
H03-RP3NA0101HJ-4 THERMISTOR ASS'Y RP3NA-0101-NZ PO72
H03-TRKTC3114NE-9 TRANSISTOR NPN KTC3114 TO-126 Q701
H03-TRKTC3114NE-9 TRANSISTOR NPN KTC3114 TO-126 Q702
H03-TRKTC3114NE-9 TRANSISTOR NPN KTC3114 TO-126 Q703
H03-TRKTC3114NE-9 TRANSISTOR NPN KTC3114 TO-126 Q704
RC3DI0282IN-3 RCF 2K8 OHM +5% 250MI0W R701
RC3DI0821IN-A RCF 820R0 OHM +5% 250MI0W R702
RC3DI0821IN-A RCF 820R0 OHM +5% 250MI0W R705
RC3DI0282IN-3 RCF 2K8 OHM +5% 250MI0W R707
RC3DI0821IN-A RCF 820R0 OHM +5% 250MI0W R708
RC3DI0821IN-A RCF 820R0 OHM +5% 250MI0W R709
RC3DI0282IN-3 RCF 2K8 OHM +5% 250MI0W R710
RC3DI0282IN-3 RCF 2K8 OHM +5% 250MI0W R711
RT6BA0201NB-A PR 200R0 OHM +30% 100MI0W VR71
RT6BA0201NB-A PR 200R0 OHM +30% 100MI0W VR72
RT6BA0201NB-A PR 200R0 OHM +30% 100MI0W VR73
RT6BA0201NB-A PR 200R0 OHM +30% 100MI0W VR74
SURROUND BD
Part Number
Description
Posistion No
3SA-4120US-SRMI-1-A IMA SURROUND BD AVR435US
H03-CEMIC01065H-1 CAP ELEC 10UF 50V M 5X11 SHL P5MM C101 203 303 503
CEMJC02275E-0 CAP ELEC 220UF 63V M 10X16 85C 120HZ ELITE P5MM C201 202 301 302 501 502
CCKID0680NN-5 CC 68PF +10% -10% 50.0V 2B4 C204 304 504
CEHGC01075E-5 CE 100U0F +20% 25.0V 6.3X11 85C P5MM C205 305 505
