Harman Kardon AVR 435 Service Manual

harman/kardon AVR435/230 Bill of material
MAIN BD
Part Number
Description
Posistion No
H03-DS05GBUSCNB-5 DIODE PG05GBUSC D1
H03-DR1N04004NA-7 D-SR 1N4004 400.0V 1.0A D101 507 508 509
H03-DZMTZ12V0NB-6 D-ZENER MTZJ 12.0V 500MI0W D204
H03-DG1N04148NB-A D-SLP 1N4148 100.0V 150E-3A
D205 206 301 302 303 304 305 306 307 308
401 402 403 404 405 406 407 408 409 410
411 412
H03-DZMTZ05V1NB-3 DIODE ZENER MTZ J 5.1B 5.1V 500MW DO-34 D207
H03-DRBU10040BA-1 D-BRDLC BRIDGE BU10-04 D501
H03-DRW204F00BA-5 DIODE BRIDGE W2-04F FRONTIER D502 505
H03-FURN2200663-8 FUSE 663 SERIES 0663 002. 250V 2.0A TIMELUG F501 502 505 506
H03-ZNMSA4004SN-A TERMLUG GND G101 102
H03-ZMC11HS0400-6 AC HEATSINK DIODE 47X26X12 AVR630 -- ME HS11
H03-ZMD11HS0400-2 HEATSINK REG. TR 68X20X50 HS12
H03-ICLM02068D2-5 IC-OPERAMP NJM2068M-TE1 DUAL SOP8 IC22
H03-ICLM07815BD-6 IC-REGPOSFXD KIA7815API NORMAL IC51
H03-ICLM07915BD-4 IC-REGNEGFXD KIA7915API NORMAL TO-220AB IC52
H03-ICKIA7824I2-2 IC-REGPOSFXD KIA7824API TO-220IS NORMAL IC54
H03-ICKIA7812I2-8 IC-REGPOSFXD KIA7812API NORMAL IC59
H03-LCNNNA050NA-7 LFA 1MM 10MM 5 LEFT 0.0MM NONE L301 302 401 402
H03-WG02SB808AA-4 WIRECONASY UNIQUE 2P 80MM UL1007 PVC DISCRETE 26 BOTH N801 802 803 804
H03-WS8262505EN-6 WIRE ASS'Y UL1533#26 250MM 2.0MM 8P WHT SHIELD N805
H03-WSE263905EN-0 WIRECONASY DL 2.0MM 15P 390MM UL1533 SHIELD 26 1 N806
H03-WG03SB821AA-0 WIRECONASY DL 2.0MM 3P 210MM UL1007 RIBBON 26 12 BOTH N807
H03-WG05SB84000-7 WIRE ASS'Y UL1007#26STR 400MM 2.0MM 5P WHT N808
H03-WG03SB82200-4 WIRE ASS'Y UL1007#26STR 220mm 2.0mm 3P WHT N809
H03-SORA40RSCNN-5 JACK RCA 4P JB040131QN WH BU RD GY NJ11
H03-SORA40RSANN-1 JACK RCA 4P JB040131ZN GN BN PP TA NJ12
SO0A18P8CNN-7 JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0 NJ13
H03-SOPA81900NN-3 CONN-SPE TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0 NJ14
H03-WN02SD00000-2 CONN 2.5MM 2 MA ST NAT 5267-02A 0 0 P801 802 803 804 809
H03-WN07SB00001-4 CONN 2.0MM 7P GIL-S-7P-S2T2-EF P806
H03-WN03SE00000-9 CON 3.96MM PITCH MOLEX 35313-0310 P807
H03-WN05SD100WH-6 CONN WAFER 2.5MM 5P 5267-05A WHT P808
H03-WN19SB00000-1 CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0 P811
H03-TRKTC3200NA-4 TR-SHPLF KTC3200BL N 100MI0A 120V
Q301 302 303 304 305 306 313 314 337 338
401 402 403 404 405 406 409 415 416 425
H03-TRKTC3198NA-9 TR-SLPLF KTC3198BL N 150MI0A Q307 308 407 408 426 441 606 608
H03-TR2SA1145NA-8 TR-SLPLF 2SA1145Y TO-92MOD P -50MI0A -150V Q309 310 411 412
H03-TRKTA1268NA-A TR-SHPLF KTA1268BL P 100MI0A 120V Q311 312 410 413 414
H03-TRKTA1360BE-5 TRANSISTOR PNP KTA1360 TO-126 Q319 320 421 422
H03-TRKTC3423BE-A TRANSISTOR NPN KTC3423 TO-126 Q321 322 423 424
H03-TR2SD2560B0-2 TRANSISTOR NPN 2SD2560 MT-100 Q333 334 437 438
H03-TR2SB1647B0-6 TRANSISTOR PNP 2SB1647 MT-100 Q335 336 439 440
H03-TRKTA1024NA-2 TR-SLPLF KTA1024 Y P 50MI0A -150V Q442
H03-TRKRC107MNA-4 TR-SLPSWA KRC107M N Q443
H03-TRKTD1302NA-6 TR-SLPLF KTD1302 B N 300MI0A 20V Q601
H03-TRKTA1266NA-6 TR-SLPLF KTA1266 Y P 150MI0A Q605 607
RC3DI0471IN-0 RCF 470R0 OHM +5% 250MI0W
R101 102 105 106 109 110 113 114 315 316
593 594
RC3DI0104IN-5 RCF 100K0 OHM +5% 250MI0W
R207 214 216 217 218 219 220 309 310 479
480 602
RC3DI0273IN-4 RCF 27K0 OHM +5% 250MI0W R209 498
RC3DI0102IN-9 RCF 1K0 OHM +5% 250MI0W R211 601
RC3DI0101IN-0 RCF 100R0 OHM +5% 250MI0W R213 215 221 609 614
RC3DI0513IN-A RCF 51K0 OHM +5% 250MI0W R223
RC3DI0274IN-2 RCF 270K0 OHM +5% 250MI0W R224
RC3DI0333IN-1 RCF 33K0 OHM +5% 250MI0W R225 305 306 403 404
RC3DI0331IN-5 RCF 330R0 OHM +5% 250MI0W R301 302 401 402
RC3DI0100IN-2 RCF 10R0 OHM +5% 250MI0W R303 304 388 389 473 474 477 478
RC3DI0433IN-8 RCF 43K0 OHM +5% 250MI0W R307 308 415 416
