harman/kardon AVR435/230 Bill of material
FRONT BD
Part Number
Description
Posistion No
RS3AD0104NA-A RES CHIP 100K0 OHM +5% 62MI5W 0603 R516
RC3DI0182IN-7 RCF 1K8 OHM 5% 1/4W R518
RS3AD0473NA-1 RES CHIP 47K0 OHM +5% 62MI5W 0603 R520
RS3BB0683NA-6 RES,CHIP,68K 1/10W +/-5%,0805 R701
RS3BB0103NA-6 RES,CHIP,10K 1/10W +/-5%,0805 R702 704 709 710
RS3BB0272NA-5 RES,CHIP,2.7K 1/10W +/-5%,0805 R703
RS3BB0564NA-3 RES,CHIP,560K OHM,1/10W +/-5%,0805 R705
RS3BB0105NA-2 RES,CHIP,1M 1/10W +/-5%,0805 R706 707
RS3BB0511NA-2 RES,CHIP,510 1/10W +/-5%,0805 R708
RS3CB0102NN-8 RES,CHIP,1K,1/8W,+/-5%,0805 R711 715
RS3BB0221NA-0 RES,CHIP,220R 1/10W +/-5%,0805 R712 713
RS3BB0471NA-A RES, CHIP 470 OHM 1/10W +/-5%, 0805 R714
RS3AD0101NA-5 RES CHIP 100R0 OHM +5% 62MI5W 0603 R746
RS3AD0563NA-0 RES CHIP, 56K 1/16W +/-5%, 0603. R821
RS3AD0221NA-6 RES CHIP 220R0 OHM +5% 62MI5W 0603 R823
RC3DI0151IN-7 RCF 150 OHM 5% 1/4W R831
RC3DI0331IN-5 RCF 330R0 OHM +5% 250MI0W R832
RC3DI0561IN-A RCF 560R0 OHM +5% 250MI0W R851 852
CCKID0101NA-7 CC 100P0F +10% -10% 50.0V Y5P REWORK C5 C6
CCKID0680NN-5 CC 68PF +10% -10% 50.0V 2B4 REWORK C7
H03-ICRPM6938NN-9 IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ RM71
H03-DPLP200LNNN-2 PIN PHOTO DIODE LP-200TL RM72
H03-ZMB01S02200-4 SPRING PLATE GND C5212 0.2T S2 4 5 6 7
H03-SWC2A112FS1-3 SWITACT VERTICAL SKQNADD010 12V 50MA
S201 202 203 204 205 206 207 208 209 210
211 212 213 214 215 216 217 218 219 220
H03-ZMD12S01A00-9 SHIELD IR SH11
H03-ZMC12S16A00-5 BKT GROUND SH12
H03-ZMD12S01B00-0 SHIELD MICROPHONE SH22
H03-SWE3A0505S1-4 SWIROT EC16B24204 5V 500U0A 10T 3P 0 0 VR100
ZFNR1SENSOR-0 RUBBER SENSOR
MAIN BD
Part Number
Description
Posistion No
3SA-4120US-MAMI-1-3 IMA MAIN BD AVR435US
CCKIC0222NA-1 CC 2N2F +10% -10% 50.0V Y5P C1 C2
CCKID0101NA-7 CC 100P0F +10% -10% 50.0V Y5P C101 102 107 108 111 112 114 115 116 209
CCKID0470NA-9 CC 47PF +10% -10% 50.0V Y5P C103 104 109 110 113 117 118
CCZID0104NA-2 CC 100N0F +80% -20% 50.0V F C119 120 212 214 527
CEHGC01075E-5 CE 100U0F +20% 25.0V 6.3X11 85C P5MM C206 208 213 309 310 405 406 526
H03-CEMIC0475AH-3 CE 4.7UF 50V M 5X11 SHL SAMYOUNG P5MM C207
CEHIC01055E-6 CE 1UF +20% 50V D5XL11 P5MM 85C C210
H03-CEMKC0106AH-9 CAP ELEC 10UF 100V M 6.3X11 SHL C211 319 320 413 414
CEHIC01065E-4 CE 10U0F +20% 50.0V 85C P5MM 5X11 C301 302 401 402 429 518 519 521
CEMJC02275E-0 CAP ELEC 220UF 63V M 10X16 85C 120HZ ELITE P5MM C303 304 305 306 421 422 423 424
CCKID0680NN-5 CC 68PF +10% -10% 50.0V 2B4 C307 308 403 404
CCKID0271NN-0 CC 270P0F +10% -10% 50.0V 2B4 C313 314 569 570
CCJIC0120NN-2 CAP CERAMIC 12PF 50V J CH TAP C315 316 409 410
CCJIC0330NE-9 CAP CERAMIC 33PF 50V +-5% NPO C317 318 411 412
CFLJC0683NN-7 CPM 68N0F +5% 63.0V C323 324 430 431
H03-CPKJC0104NN-2 CAP POLY NON METAL 0.1UF 63V K TAP PCMT365 75104 C325 326 327 328 417 418 419 420
CCKIC0222NA-1 CC 2N2F +10% -10% 50.0V Y5P C329 330 425 426
CEHEC02275E-9 CE 220UF +20% 10.0V D6.3XL11 P5MM 85C C331 332 407 408
CCMFD0472NN-6 CC 4N7F +20% -20% 16.0V Y5R C333 434
CEMGC04775E-9 CE 470U0F +/-20% 25.0V 10X13 85C C432
CCMFD0103NN-4 CC 10N0F +20% -20% 16.0V Y5S C433 601 602
CFIOC0104NN-5 CPM 100N0F +10% 250.0V C501 502 503
H03-CEMJA0129KB-8 CAP ELEC 12000uF 63V M 35x45 LSW123M1JQ45M C504 505
CPIKC0473NN-0 CPF 47N0F +10% 100.0V C506 507 508 516 528 529
CEHHC0228MN-A CE 2MI2F +20% 35.0V 85C ELITE C509 510
CEHIA0228MN-4 CE 2MI2F +20% 50.0V 85C ELITE C517
Hanrman Consumer Group International
