harman/kardon AVR435/230 Explode view part list
NO Part numbe
DESCRIPTION
1
H03-ZMC11S00200
AL DOOR AVR 1
2
H03-ZMC11S00300
AL PANEL AVR 1
3
H03-ZMC12S20A00 BADGE AL HARMAN/KARDON SILVER 1
4
H03-ZMGEN00GAGY
AL LOGO BADGE TOP 1
5
H03-ZMC11S08A00 COVER TOP AVR 1
6
H03-ZVC11DWT200 TAPE PANEL 1
7
H03-ZVC11DWT100 TAPE DOOR 1
8
H03-ZMD12S01A00 SHIELD IR 1
9
H03-SOSS9CKX3NN JACK PHONE 6.35 H70980110S 9P BK 1
10
H03-ZMB01S00100 BKT HEADPHONE JACK 1
11
H03-SWA2B21PDA& SW PUSH POWER SDDLB15700 5A 250V 1
12
ZPC1006GAWH BUTTON STANDBY 1
13
ZPC1003GAGY BUTTON POWER 1
14
ZPC1007GAMW INDICATOR STAND-BY 1
15
H03-ZMC11S12A00 CAP BUTTON STAND-BY 1
16
ZFD122062SB RUBBER TOP 20X15X6.2t 1
17
ZPD1201GAGY PANEL FRONT 1
18
H03-ZMC11S14A00 BKT DOOR 1
19
ZPC1002GAGY DOOR AVR 1
20
H03-ZMD05S16A00 BKT HINGE 2
21
H03-ZPC1018GART FILTER VFD 1
22
H03-ZPD1119GABT WINDOW DISPLAY AVR435+BADGE NAME 1
23
H03-ZPD0317GACR CAP KNOB VOLUME 1
24
H03-ZPD0316GASG COVER KNOB 1
25
H03-ZPD0315GAMW VOLUMN KNOB 1
26
H03-ZVC11GEAR01 DAMPER GEAR DP120 1
27
ZPC1102GAMW INDICATOR VIDEO 4 2
28
ZPC1005GAGY BUTTON 8 KEY 1
29
H03-ZPC1004GASG BUTTON 7 KEY 1
30
ZFNR19720SB RUBBER FOOT 19.7X19.7X2T BK 4
31
ZPC1103GAGY FOOT 50MM 15.8MM 4
32
H03-ZMC11S13A00 CH MAIN 1
33
H03-SORA3313PNN JACK RCA 3P YWR 1
34
H03-SORA8OSC5N8 JACK S-VIDEO 1P C40160261N 1
35
H03-ZMC12S17A00 SHIELD DIGITAL 1
36
H03-SORA1JE01NN JACK RCA 1P JE010003MN GND OR 1
37
H03-SOTOR179LB
D-LEM TORX-179L 4
38
H03-SO3P5179NNN JACK PHONE 3.5PI PJ0435179N 1
39
ZFD122072SB RUBBER TOP 20X20X7.2t 1
40
H03-ZMC11S06A00 SPRING STOPPER 1
41
H03-SWE3A0505S1 SW ROT EC16B24204 5V 500U0A 10T 3P 0 0 1
42
H03-ZMD12S01B00 SHIELD MICROPHONE 1
43
H03-VDHCA18LL03 FL HCA-18LL03 1
44
ZPC1017GAB
HOLDER VFD 1
45
H03-ZMC11S07A00 CH FRONT 1
46
ZFNR1SENSOR RUBBER SENSOR 1
47
H03-ZVC11FAN100 FAN JF0925S1L 1
48
H03-ZMC11S09A00 BKT FAN FRONT 1
49
H03-ZMC12S08B00 BKT TRANS BOTTOM 1
50
H03-TXPWMMD20B0 POWER TRANSFORMER 1
51
H03-ZMC12HS0100 HEATSINK 17*15*30 1
52
H03-SOPA20019B
AC OUTLET 1
53
ZMC12S15AYE STANDOFF HEX M4X0.7 6X111.2H 1
54
H03-ZMC12S19A00 BKT AC INLET 2
55
H03-ZMD12S04B00 BKT FRAME GUIDE 1
56
H03-ZMD12HS0100 HEATSINK H/SINK AMP 1
57
H03-ZMC12S09A00 BKT HEATSINK 7
58
H03-SOPA8SH0612 JACK SPEAKER 6P SH0612707P 1
59
H03-SORA11Y00NN JACK RCA+S VIDEO C5016031DN 7
60
H03-ZMC12S16A00 BKT GROUND 1
