Harman Kardon AVR 435 Service Manual

harman/kardon AVR435/230 Explode view part list
NO Part numbe
r
DESCRIPTION
61
H03-SOJW2350SNN JACK PHONE 3.6 EP-1401A 1P BK 4
62
SOPA96063NN JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
63
H03-ZMC11HS0200 H/SINK MAIN 1
64
H03-ZMC11S10A00 BKT FAN REAR 1
65
H03-SORA40GNDNN JACK RCA 4P JB040131PN WWRR 5
66
H03-ZMD20S02A00 PANEL REAR 1
67
H03-ZVC11TUNE01 TUNER MODULE KST-MB011MW0-81 US 1
68
H03-SOJB04013HN JACK RCA 4P OR ,OR, OR, OR JB040131HN 1
69
H03-SOTOT179LB
A
D-LEM TOTX-179L 1
70
H03-SORA40RSANN JACK RCA 4P JB040131ZN GN BN PP TA 2
71
H03-SORA40RSCNN JACK RCA 4P JB040131QN WH BU RD GY 2
72
H03-ZMC11S04B00 BKT FRAME GUIDE 1
73
ZMC12S13AYE STANDOFF HEX M4X0.7 6X31.9H 3
74
SO0A18P8CNN JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0 1
75
H03-SOPA81900NN TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0 1
76
H03-ZMC11HS0400 HEATSINK DIODE 47X26X12 AVR630 -- ME 1
77
ZMC12S14AYE STANDOFF HEX M4X0.7 6X61.9H 3
78
H03-ZMD11HS0400 HEATSINK REG. TR 68X20X50 1
79
ZMC1221AA00 CLAMP WIRE-FIX UL 55212250 1
80
ZFNR13830SB RUBBER SIDE 50X22X3t 6
81
H03-ZMC12S07A00 COVER BOTTOM 1
82
ZUC1201AABK SPONGE 30X30X10T BK 3
83
H03-SOR12BJ12NN JACK RCA 12P BJ120154JN 1
SW
H03-SWC2A112FS1 SWITACT TACT SKQNADD010 12V 50MA 20
H03-ZMB01S02200 SPRING PLATE GND C5212 0.2T 8
N1
ZNSSM4045HZ NUT M4 HEXAGON CIRCULAR EXTERNAL 4
S1
ZSTBM3010BB SCREW ST BH 3X10 64
S2
ZSTWM3008BY SCREW ST WPH 3X8 49
S3
ZSMCM4010BB SCREW BM 4X10 4
S4
ZSTWM4008BC SCREW ST WPH 4X8 SILVER CHROM 12
S5
ZSTWM3006BB SCREW ST WPH 3X6 7
S7
ZSTBM3012BY SCREW ST BH 3X12 PIVOT 36
S8
ZSMCM4008BY SCREW BM 4X8 5
SG
ZSTGM3010BB SCREW ST BH 3X10 GROUND 50
W1
ZWM623108SZ WASHER SPRING 3 39
W2
ZWM803305PZ WASHER PLAIN 3 20
W3
ZWM763109SZ WASHER SPRING 4 4
W4
ZWMC04810PZ WASHER PLAIN 4 4
