Harman Kardon AVR 7200 Service Manual

MITSUMI
Video Switch · 75Ω driver · Y/C mix MM1501
Item Symbol Measurement conditions Min. Typ. Max. Unit
Consumption current I
CC Refer to measurement procedures 3.3 4.3 mA
Input pin voltage V
IN No-signal, no-load 1.80 2.00 2.20 V
Output pin voltage V
OUT No-signal, no-load 1.25 V
Voltage gain G
V Refer to measurement procedures - 0.5 0 +0.5 dB
Frequency characteristic fc Refer to measurement procedures
- 10+1dB
Differential gain DG Refer to measurement procedures
- 30+3%
Differential phase DP Refer to measurement procedures
- 3 0 +3 deg
Total harmonic distortion ratio THD Refer to measurement procedures 0.03 0.3 %
Output dynamic range V
D Refer to measurement procedures 2.6 2.9 V
Output offset voltage V
OFF Refer to measurement procedures ±15 mV
Cross talk C
T Refer to measurement procedures - 70 - 60 dB
SW input voltage H V
IH Refer to measurement procedures 2.1 V
SW input voltage L V
IL Refer to measurement procedures 0.7 V
Input impedance Zo 75 Ω
MM1503
Item Symbol Measurement conditions Min. Typ. Max. Unit
Consumption current I
CC Refer to measurement procedures 4.4 5.7 mA
Input pin voltage V
IN No-signal, no-load 1.20 1.40 1.60 V
Output pin voltage V
OUT No-signal, no-load 1.25 V
Voltage gain G
V Refer to measurement procedures 5.5 6.0 6.5 dB
Frequency characteristic fc Refer to measurement procedures
- 10+1dB
Differential gain DG Refer to measurement procedures
- 30+3%
Differential phase DP Refer to measurement procedures
- 3 0 +3 deg
Total harmonic distortion ratio THD Refer to measurement procedures 0.03 0.3 %
Output dynamic range V
D Refer to measurement procedures 2.6 2.9 V
Output offset voltage V
OFF Refer to measurement procedures ±30 mV
Cross talk C
T Refer to measurement procedures - 70 - 60 dB
SW input voltage H V
IH Refer to measurement procedures 2.1 V
SW input voltage L V
IL Refer to measurement procedures 0.7 V
Input impedance Zo 12 Ω
MM1504
Item Symbol Measurement conditions Min. Typ. Max. Unit
Consumption current I
CC Refer to measurement procedures 6.5 8.5 mA
Input pin voltage V
IN No-signal, no-load 2.35 2.55 2.75 V
Output pin voltage V
OUT No-signal, no-load 2.55 V
Voltage gain G
V Refer to measurement procedures - 0.5 0.0 0.5 dB
Frequency characteristic fc Refer to measurement procedures
- 10+1dB
Differential gain V
CC=9V DG Refer to measurement procedures - 30+3%
Differential phase V
CC=9V DP Refer to measurement procedures - 3 0 +3 deg
Output dynamic range V
D Refer to measurement procedures 2.6 3.0 V
Output offset voltage V
OFF Refer to measurement procedures ±15 mV
Cross talk C
T Refer to measurement procedures - 70 - 60 dB
SW input voltage H V
IH Refer to measurement procedures 2.1 V
SW input voltage L V
IL Refer to measurement procedures 0.7 V
Input impedance Zi 15 kΩ
MM1505
AVR7200 harman/kardon
125
