Harman Kardon AVR 7200 Service Manual

AVR7200 EXPLODED VIEW PART LIST
Ref
#
Part
#
Qty Description
1 5523066
0
1PC
A
C PUN COVER TOP AVR8000 METAL --
2 5523129
0
1 PC SWIPUSH POWER SWITCH J46208000004 8.0A 250.0V 100MI0OHM 1T 2P
3 5523051
0
1PC
A
C PUN BRACKET SW POWER AVR8000 --
4 5523034
0
1PC
A
C MLD HOLDER GUIDE POWER SW AVR800
5 5517781
0
1PC
A
C DEC BUTTON POWER HIPS DVD10 --
6 5514527
0
1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
7 5517802
0
1PC
A
C MLD BUTTON INDICATOR STAND-BY AVR520 --
8 5517782
0
1PC
A
C DEC BUTTON STANDBY --
9 5523028
0
1PC
A
C DEC ENDCAP LEFT HIPS AVR8000
10 5517780
0
1PC
A
C DEC CRYSTAL FILTER DISPLA
Y
11 5517799
0
2PC
A
C DIFFUSER 0.2T 59.6*41 WH NON-METAL
12 5527316
0
1PC
A
C DEC GUIDE BUTTON 5KEY --
13 5557722
0
1PC
A
C DEC CRYSTAL WINDOW DISPLAY AVR7200
14 5517862
0
1PC
A
C PRI LABEL "PLEASE" AVR520
15 5557716
0
1PC
A
C CPL CABINET AL PANEL AVR720
0
16 5523047
0
1PC
A
C DEC KNOB MAIN HIPS AVR8000
17 5517775
0
3PC
A
C DEC KNOB TONE HIPS
18 5559795
0
2PC
A
C PUN PLATE SPACE AVR7500
19 5526220
0
1PC
A
C DEC CABINET PANEL FRONT AVR7500
20 5523032
0
1PC
A
C DEC ENDCAP RIGHT HIPS AVR8000
21 5517803
0
2PC
A
C MLD BUTTON INDICATOR VIDEO 4 AVR520 --
22 5512543
0
1 PC D-LEM TORX178B RD RND C
L
23 5517595
0
1 PC CON PHONO SCKT RCA 1P W/GND JE010003MN
24 5518255
0
1PC
A
C PUN SHIELD DIGITAL ET
25 5512435
0
1PC
A
C PUN BRACKET HEADPHONE RT2280/RT2250(PAV5007/5005) -
-
26 5505069
0
1 PC CONN-PHJAC 6.35 ST HORZ CKX3-6.35-04 BK 0
0
27 5549878
0
1PC
A
C DEC BUTTON 7 KEY AVR7200/8200 -
-
28 5557736
0
1PC
A
C DEC BUTTON 3 KEY SET AVR7200 --
29 5557738
0
1PC
A
C DEC BUTTON 5 KEY SET AVR7200/8200 --
30 5514278
0
1 PC DISPLAY HNA-15LL01
31 5517992
0
2 PC PR-ROT 100K0 OHM NON-LINEAR RK14K12400BR 0
0
32 5511396
0
1 PC CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J
33 5517151
0
1 PC CON PHONO SCKT RCA-313P 3 PINS
34 5517896
0
1PC
A
C SPRING PLATE SPRING GND C5212 0.2T AVR520
35 5517991
0
1 PC PR-ROT 100K0 OHM NON-LINEAR RK14K12400BQ 0
0
36 5517757
0
1PC
A
C PUN SHIELD FENCE TONE
37 5513490
0
1 PC SWIROT EC16B24204A5 5V 500U0A 10T 3P 0 0
38 5517894
0
1PC
A
C MOLD REFRACTOR E WH PL
39 5519153
0
1PC
A
C PLASTIC MOLD REFRACTOR B WH
40 5517844
0
1PC
A
C MLD HOLDER FL-GUIDE HIPS 94HB AVR52
0
41 5515593
0
1 PC IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KH
Z
42 5517796
0
1PC
A
C DIFFUSER REFLECTOR C WH NON-METAL
43 5517893
0
1PC
A
C MOLD REFRACTOR F WH PL
44 5514915
0
1PC
A
C PRI LABEL RISK CDRW1211
45 5562955
0
1PC
A
C CPL CABINET CHASSIS FRONT AVR7200
46 5523056
0
2PC
A
C PUN BRACKET TOP AVR8000 --
47 5523057
0
2PC
A
C PUN BRACKET SIDE SECC1.0T AVR8000 -
-
48 5527593
0
3PC
A
C RAW SHIELD FORM GASKET 71TSN 10-8-33-00
49 5562946
0
1PC
A
C HEATSINK POWER 3CH AVR7200 -- METAL
50 5516871
0
15 PC
A
C PUN BRACKET HEATSINK
51 5563717
0
1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/WH D/N B30290117N FE 19MM
52 5563718
0
1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/BU D/N B30290118N FE 19M
M
53 5563719
0
1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/BN D/N B30290119N FE 19M
M
54 no need(only europe version
)
AVR7200 harman/kardon
19
