Harman Kardon AVR 7200 Service Manual

AVR7200 Electrical Parts List
Ref
Designator
Part Number Qty Description
Main PCB
Capacitors
C210 2041669071 1 PC CPM 100N0F +20% 250.0V
C211 2041669071 1 PC CPM 100N0F +20% 250.0V
C212 2041669071 1 PC CPM 100N0F +20% 250.0V
C223 208519800 1 PC CE 3MI3F +20% 50.0V 85C
C242 55126160NR 1 PC CE 6MI8F +20% 16.0V 85C
C243 13039870AM 1 PC CE 2MI2F +20% 16.0V 85C
C244 553153000 1 PC CE 4MI7F +20% 35.0V 85C
C245 553153000 1 PC CE 4MI7F +20% 35.0V 85C
C252 55232360NR 1 PC CE 2MI2F +20% 100.0V 85C
C253 55232360NR 1 PC CE 2MI2F +20% 100.0V 85C
C226 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C229 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C232 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C235 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C238 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C241 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C248 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C251 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C261 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C262 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C263 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C264 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C265 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C266 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C267 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C268 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C269 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C270 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C271 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C272 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C273 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C274 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C275 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C276 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C201 1036482071 1 PC CPF 47N0F +10% 100.0V
C202 1036482071 1 PC CPF 47N0F +10% 100.0V
C203 1036482071 1 PC CPF 47N0F +10% 100.0V
C204 1036482071 1 PC CPF 47N0F +10% 100.0V
C205 1036482071 1 PC CPF 47N0F +10% 100.0V
C206 1036482071 1 PC CPF 47N0F +10% 100.0V
C207 1036482071 1 PC CPF 47N0F +10% 100.0V
C208 1036482071 1 PC CPF 47N0F +10% 100.0V
C209 1036482071 1 PC CPF 47N0F +10% 100.0V
C224 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C225 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C227 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C228 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C230 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C231 20269180AM 1 PC CE 1MI0F +20% 6.3V 85C
C233 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C234 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C236 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C237 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C239 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C240 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C246 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C247 5521357030 1 PC CE 220U0F +20% 25.0V 85C
C249 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C250 5521357030 1 PC CE 220U0F +20% 25.0V 85C
C254 2026818030 1 PC CE 330U0F +20% 16.0V 85C
26
