Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
Main PCB
Semiconductors
D201 55125540NR 1 PC D-BRDLC BU6-04F
D202 55179300NR 1 PC D-BRDLC BRIDGE W2-04F FRONTIER
D203 55248910NR 1 PC D-BRDLC BU4-04F
D204 55248910NR 1 PC D-BRDLC BU4-04F
IC01 55505780MU 1 PC IC-REGPOSFXD KIA7824API TO-220IS NORMAL
IC02 55505780MU 1 PC IC-REGPOSFXD KIA7824API TO-220IS NORMAL
IC03 55123960MU 1 PC IC-REGPOSFXD KIA7805API NORMAL
IC04 55125450MU 1 PC IC-REGPOSFXD BA033T NORMAL
IC05 55123960MU 1 PC IC-REGPOSFXD KIA7805API NORMAL
IC06 55123990MU 1 PC IC-REGNEGFXD KIA7905PI NORMAL
IC07 20832440MU 1 PC IC-REGPOSFXD KIA7815API NORMAL
IC08 55124020MU 1 PC IC-REGNEGFXD KIA7915PI NORMAL
IC09 55207930KV 1 PC PHOTCOUP PC-17T1
IC10 55207930KV 1 PC PHOTCOUP PC-17T1
D205 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D206 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D207 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D208 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D209 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D211 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D212 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D213 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D214 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
Q201 5517922056 1 PC TR-SLPSWA KRA107M P
Q202 5517922056 1 PC TR-SLPSWA KRA107M P
Resistors
R201 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R202 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R203 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R204 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R206 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R207 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R208 552288400 1 PC RW 5R6 OHM +5% 3.0W 100PPM/'C -100PPM/'C
R209 552288400 1 PC RW 5R6 OHM +5% 3.0W 100PPM/'C -100PPM/'C
R220 1013600091 1 PC RMGCFMIC 8K2 OHM +5% 62MI5W
R221 1013512091 1 PC RMGCFMIC 22K0 OHM +5% 62MI5W
R222 1013512091 1 PC RMGCFMIC 22K0 OHM +5% 62MI5W
R231 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R232 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R233 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R234 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R235 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R236 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R237 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R238 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R240 1013592091 1 PC RMGCFMIC 3K9 OHM +5% 62MI5W
R241 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R242 1013522091 1 PC RMGCFMIC 47K0 OHM +5% 62MI5W
R243 1013522091 1 PC RMGCFMIC 47K0 OHM +5% 62MI5W
R244 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R246 1013491091 1 PC RMGCFMIC 470R0 OHM +5% 62MI5W
R247 1013485091 1 PC RMGCFMIC 270R0 OHM +5% 62MI5W
R248 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
Miscellaneous
55127070 8 PC SCREW-ST 3MM 10MM JIS B 1122 J5636140010X 19 0 0
55127300 8 PC WASHER-SPR 3.1MM 6.2MM 0.8MM Y 53 0 I4
F200 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F201 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F202 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F203 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F204 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
27
