Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
Main PCB
F205 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F206 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
F207 555052000 1 PC FUSE 2.0 A 250.0 V 0 A1
G101 55135980NR 1 PC TERMLUG GND
G202 55176300 1 PC AC PUN BRACKET GROUND MECHA RTDVD1 --
HS51 55194550 1 PC AC HEATSINK 60*20*50H AL6063S-T5 -- ME
HS52 55194550 1 PC AC HEATSINK 60*20*50H AL6063S-T5 -- ME
HS53 55194550 1 PC AC HEATSINK 60*20*50H AL6063S-T5 -- ME
HS54 55194550 1 PC AC HEATSINK 60*20*50H AL6063S-T5 -- ME
N203 556868200 1 PC WIRECONASY UNIQUE 3P 250MM UL1007 RIBBON 22 1
N204 556868200 1 PC WIRECONASY UNIQUE 3P 250MM UL1007 RIBBON 22 1
N205 551641500 1 PC WIRECONASY UNIQUE 4P 160MM UL1007 PVC 26 1
N209 551835800 1 PC WIRECONASY UNIQUE 9P 150MM UL1007 PVC 26 1
NJ01 55317130 1 PC CON PHONO SCKT RCA 4P JW-4104RC WH,BU,RD,GA
NJ02 55317140 1 PC CON PHONO SCKT RCA 4P JW-4104RA GN,BN,PP,TA
NJ03 55176390 1 PC CON PHONO SCKT STEREO JACK JW350S
NJ04 55176390 1 PC CON PHONO SCKT STEREO JACK JW350S
NJ05 55176390 1 PC CON PHONO SCKT STEREO JACK JW350S
P201 55146620 1 PC CONN 2.5MM 7 MA ST NAT 0 0
P202 55146610 1 PC CONN 2.5MM 6 MA ST NAT 0 0
P205 55174630 1 PC CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
P208 55174630 1 PC CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
P210 55124800 1 PC CONN 1.25MM 15 FE ST BK 00-8370-151-000-800 2794 A6
P211 55124960 1 PC CONN 2.0MM 11 MA ST NAT MOLEX 35336-1110 0 0
FRONT PCB
Capacitors
C106 551343600 1 PC CM 47MI0F +80% -20% 5.5V 70C
C136 1036482071 1 PC CPF 47N0F +10% 100.0V
C141 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C314 55179410NR 1 PC CPM 82N0F +5% 100.0V
C315 55179410NR 1 PC CPM 82N0F +5% 100.0V
C100 1013842091 1 PC CCCFMIC 820P0F +10% -10% 50.0V X7R
C101 1013842091 1 PC CCCFMIC 820P0F +10% -10% 50.0V X7R
C102 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C105 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C109 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C111 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C112 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C113 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C115 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C116 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C117 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C118 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C120 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C121 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C122 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C123 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C124 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C125 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C126 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C127 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C128 2050659091 1 PC CCCFMIC 100P0F +5% -5% 50.0V NP0
C129 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C130 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C139 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C140 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C144 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C220 1013879091 1 PC CCCFMIC 22N0F +80% -20% 50.0V Y5V
C221 1013879091 1 PC CCCFMIC 22N0F +80% -20% 50.0V Y5V
C103 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C104 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C107 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C108 2026895030 1 PC CE 100N0F +20% 50.0V 85C
C110 2026901030 1 PC CE 47U0F +20% 50.0V 85C
28
AVR7200 harman/kardon
